26
Organ Section
9
The VIVO S2 has a section that simulates famous electric organs. You can
select many presetted organ sound and create a wide variety of tonalities
and save them in the instrument's internal memory. You can add various
typical eects of an electric organ as a Leslie speaker.
Selecting Presetted Organ Sounds
1. Select the organ model you desired. See "Selecting Various
Organ Types" (p. 26).
2. Before to operate a tone change you need to select on
which part you want to do it. See "How to Select a Part" (p.
22).
3. Press the [ TW ORGAN ] button to select the tonewheel organ
family.
The last sound you selected for the organ category is recalled.
The [ TW ORGAN ]button indicator lights and a temporary window
shows the list of draw-faders where the recalled combination is
underlined:
'Manual' is the current footage conguration.
The other items of the list indicate the most used combinations.
Each number indicates the amount of volume for each foot. For
example, the '00 5320 000' corresponds to the following position of
'virtual' drawbar:
00 5320 000
4. While the tone window is active, use the[] [] buttons
to select a dierent preset. The preset conguration is
recalled.
MEMO
If during normal operation the window closes automatically,
press the [ TW ORGAN ] button again.
Selecting Various Organ Types
The VIVO S2 comes with various organ models that reproduce the tonal
characteristics of both tonewheel and transistor types organ: TW1, TW2,
FARF, VX and PIPE. Moreover you have two user organ memory location
(USER 1, USER 2) that allows you to expand the tonal resources of the
instrument. You can download this selection of sounds from the www.
dexibell.com website. See "How To Load Sound Libraries From a USB
Memory" (p. 37).
1. Select a preset organ sound. See "Selecting Presetted
Organ Sounds" (p. 26).
The display shows a page like this:
The organ tone is shown as follows:
Organ Type
Footage Indication Level
2. Press the 'T2L EDIT' function button and using the [] []
buttons, select 'ORGAN TYPE'.
3. Press the [] button to access the ORGAN TYPE page.
4. Use the [] [] buttons to select the desired organ type.
The selected organ type is now available for all parts.
Organ Type Explanation
TW1
It's a simulation of a organ style cabinet that use an tonewheel
apparatus for generating electric musical note.
TW2
It's a simulation of an 'home organ' style cabinet with some built-
in speakers' that use an tonewheel apparatus for generating
electric musical note.
FARF This is a simulation of a portable transistors-based organ.
VX This is a simulation of transistor-based combo organ.
PIPE
This simulate a pipe organ. It's a musical instrument that
produces sound by driving pressurized air through organ pipes.
USER1
You can download sounds from the www.dexibell.com website.
See "Additional Sound (Sound Library)" (p. 36).
USER2
