27
Four Hands Mode
9
This function divides the keyboard into two sections, left and right zone,
so that two people can play the same range of pitches, just as though
there were two pianos.
When this mode is active, it is as if you have two separate 44-keys pianos
with the same playing range and octave.
The right pedal acts as a damper pedal for the right piano section.
The left pedal must be assigned as the damper pedal for the left piano
section (see below).
Entering in "4 Hands" mode
NOTE
The "4Hands" mode is available if the "4Hands" parameter in
the "GLOBAL" section is set in "4Hands" (default). Please see "4
Hands" (p. 63).
1. To enter into "4 hands" mode, simultaneously press the [
] and [ ] button.
Sound C
Split Point
Sound A
Sound A + Sound B
Sound A
Sound A
Split Point
Sound A + Sound B
Sound C
Split Point
The instrument is now in the "4 Hands" mode.
NOTE
The default four hands mode split point is set between keys B3
and C4.
Assigning the damper for the left piano section.
To assign the left pedal as a damper for the left section, please
follow the next instructions.
Damper pedal for
the right section
Damper pedal for the left section.
See below how to assign it.
2. To enter in "4 hands" settings, press and hold the [
] and [
] button until the following page is displayed.
The display shows the "4 HANDS MODE" page:
3. By the [] [] buttons select the "Left Damper"
parameter and press the [] button to set it "ON".
Now you are ready to have a four-hand performance.
4. To leave the "4 hands" mode, simultaneously press the
[
] and [ ] buttons or press one of the two
bottons individually.
How to Adjust the Volume Balance
Between the Left and Right Piano Section
In the "4 HANDS MODE" page, you can adjust the "Balance" and
"Output" parameters.
5. Use the [] [] buttons to select the parameter that you
want to adjust.
6. Use the [] [] buttons to set the desired value.
Parameter Setting Explanation
Balance 90:10 ~ 50:50 ~ 10:90
Adjust the balance between the Left
and Right piano section.
Output <L R>, L&R
Select the audio signal output socket.
<LR>: The sound of the Left piano
section will be heard only from the left
speakers.
The sound of the Right piano section
will be heard only from the right
speakers.
L&R: The sound of the Left and Right
piano section will be heard from both
speakers (Left and Right).
NOTE
If using headphones, you have the
same behaviour as speakers.
How to Choose the Tone for the 4 Hands
Mode
You have the option to choose which tone will be recalled when entering
4 hands mode by the "Sound" parameter".
7. From the "4 HANDS MODE" use the [] [] buttons to
select the "Sound" parameter and use the [] [] buttons
to select your favourite tone.
NOTE
Please take note that this parameter is automatically saved in
the memory Global area when the instrument is turned o.
