DXPGH2SB21 / DXPGB2WD21
30
SERVICING
Replacing the Comfort Pads
Brow pad
Remove brow comfort pad by pulling away from the ‘hook and loop’ retaining strip,
whilst referring to “Removing & Replacing the Face Seal” on page 23.
Place the new brow pad onto the ‘hook and loop’ strip. Ensure the brow pad is placed
centrally to the front of the headband so that it sits equally left and right to the user’s
head.
Ensure the ‘perforated’ side of the brow pad is facing the user’s skin.
Crown pad
Pull the crown pad away from the headband straps.
Place the new crown pad inside the headband and insert the straps into the
corresponding slots. Position cut-out marker to the front of the headband.
Ensure the ‘perforated’ side of the crown pad is facing the user’s skin.
Nape pad
Remove nape comfort pad by pulling away from the ‘hook and loop’ retaining strip.
Place the new nape pad onto the ‘hook and loop’ strip. Ensure the nape pad is placed
centrally to the headband adjuster.
Ensure the ‘perforated’ side of the nape pad is facing the user’s skin.
High Efficiency Particulate Air Filter Replacement
When the status indicator LED illuminates RED, further investigation is required regarding
condition of a filter and a battery. If no fault on battery has been found, the high efficiency
particulate (HEPA) filter must be replaced.
Install a new HEPA filter as shown in Figure 41- Figure 42 and Figure 7 on page 14.
Doff the respirator.
Turn off the respirator and open the filter
cover, by releasing the latches on both sides
of the respirator as shown in Figure 41 and
Figure 42.
Figure 42
Figure 41
