ENGLISH

4

Bluetooth® Status Indicator LED

Blink Patterns Status/Mode

Continuously Single

Blinks

Speaker Bluetooth® is on.

Continuously

Double Blinks

Speaker is in pairing mode and

discoverable by yourdevice.

Solid light Speaker is connected with adevice.

No light Speaker has timed out and/or isoff.

Connecting a Previously Paired Bluetooth® AudioDevice

If a Bluetooth® device has been previously paired to the

speaker, it should automatically reconnect when the speaker

is powered on.

NOTE: The Bluetooth® audio device must have Bluetooth®

turned on to automaticallypair.

1. If connection does not occur and you are unable to

stream audio, please follow the instructions for Pairing

Speaker with a Bluetooth® AudioDevice.

Stereo Pairing with Two Speakers

1. On both speakers, simultaneously press and hold the

Bluetooth® button

6

for three seconds.

2. Speakers will say "left channel" or "right channel" to

indicate that pairing was successful.

3. The Bluetooth® status indicator LED

4

will be blue on the

left channel speaker and the Bluetooth® status indicator

LED

4

will not be illuminated on right channel speaker.

Timeout Functionality (Fig. A)

To conserve battery life, the speaker is designed to power

off automatically after fifteen minutes of inactivity. This

inactivity could be due to the device being unpaired for

fifteen minutes or the Bluetooth® connection being broken

for the same period of time. If the speaker powers off due

to inactivity of any kind, refer to Connecting a Previously

Paired Bluetooth® AudioDevice.

Bluetooth® Range

Optimum Bluetooth® streaming range is roughly 30 ft. (9m)

with a straight line of sight to the speaker, but distances

up to 100 ft. (30m) are possible. Physical obstacles, other

wireless devices or electromagnetic devices may affect the

connectionquality.

• If Bluetooth® connection is lost due to exceeding time of

separation, exceeding the optimum distance, obstacles

or otherwise, reconnecting your device with the speaker

may benecessary.

Incoming Call

• If your phone receives a call while it is connected to the

speaker, it will pause the Bluetooth®connection.

• When the call is disconnected, the speaker will

automatically switch back to the Bluetooth®connection.

Playing Audio

Audio can be played through the speaker via a wireless

Bluetooth® connection to a compatible Bluetooth® audio device.

Pairing Speaker with a Bluetooth®

AudioDevice (Fig. A)

1. Place the speaker and the Bluetooth® audio device within

3 ft. (1m) of eachother.

2. Turn on the speaker by pressing and holding the power

button

1

until you hear a sequence of tones. The Bluetooth®

status indicator LED

4

will continuously single blink.

3. Ensure the Bluetooth® audio device has Bluetooth®

turned on. (Please consult your device's instruction

manual for specific pairing instructions.)

4. Momentarily press the Bluetooth® button

6

on

thespeaker.

5. The blue Bluetooth® status indicator LED

4

will

continuously double blink and you will hear tones from

the speaker indicating the speaker is in pair mode.

6. Select

DeWALT DCR008 on your device and

confirmpairing.

7. Once pairing is successful, the Bluetooth® status indicator

LED

4

will remain illuminated blue and you will hear a

tone from the speaker.

8. The speaker will now play audio from yourdevice.

NOTE: Audio output power:1x5W.

Button Functions (Fig. A)

Power Button

• To turn the speaker on or off, press and hold the

power button

1

until you hear a sequence of tones

from thespeaker.

• When the speaker is on, momentarily press the power

button

1

and the speaker will say the percentage of

charge remaining in the battery.

• If the speaker does not respond when buttons are

pressed, press and hold the power button

1

for ten

seconds to reboot the speaker.

Play/Pause Button

When audio device connected via Bluetooth®: Press the

play/pause button

5

to begin playing a selection from the

audio device.

• Press the play/pause button

5

again to pauseplay. Press

again to resume play.

• To advance to the next track, press the play/

pausebutton

5

twice quickly.

• To skip to previous track, press the play/pause button

5

three times quickly.

Volume Adjustment Buttons

The volume buttons

2

,

3

can be used to increase or

decrease volume on thespeaker.

• The volume will increase or decrease one level with a

quick press of either volume buttons

2

,

3

.

• The volume will increase continuously with a long press

of either volume buttons

2

,

3

.

OPERATION
