3

English

Checking State of Charge (Fig. A)

• When the speaker is powered on, momentarily press the

power button

1

and the speaker will say the percentage

of charge remaining in the battery.

• The charge indicator LED

12

will also indicate the state

of charge when the speaker is not being charged per the

Charge Indicator LED Status chart.

nOTE: The state of charge does not indicate tool

functionality and is subject to variation based on product

components, temperature and end-userapplication.

Charge Indicator LED Status

lEVEl OF

ChARgE

ChARgE inDiCATOR

lEDCOlOR

UNIT ON AND

NOT CHARGING

≥40% Green

20% - 40% Yellow

≤20%

Red and blinking.

If 3% or less of charge remains, the speaker

will say "Battery low, please recharge."

UNIT OFF AND

CHARGING

0% - 99% Red

100% No illumination

UNIT ON AND

CHARGING

0% - 99% Red

100% Green

Charging Procedure (Fig.A, B)

1. Pull the USB charging port cover

11

away from thespeaker.

2. Insert the USB charging plug

10

into the charging port

13

.

3. Plug the USB charger plug

9

into any USB charging port

(such as on a computer or wall adapter).

nOTE: Charging takes two hours depending on power

supply rating (5V, 1A).

4. The charge indicator LED

12

color will be red and remain

continuously on whilecharging.

5. Charging is complete when the charge indicatorLED

12

color is green or turns off.

6. The battery can be left charging or the USB charging

cable can bedisconnnected.

Hot/Cold Delay

When the speaker detects that the battery is too hot or too

cold, it automatically starts a hot/cold delay, suspending

charging until the battery has reached an appropriate

temperature. The speaker then automatically switches to

charging mode. This feature ensures maximum batterylife.

1. A cold battery may charge at a slower rate than a

warmbattery.

2. The unit can still be used during the over temperature

protection cycle.

Important Charging Notes

1. The speaker may become warm to the touch while

charging. This is a normal condition, and does not

indicate a problem. To facilitate the cooling of the

speaker after use, avoid placing the speaker in a

warm environment such as in a metal shed or an

uninsulatedtrailer.

2. If the speaker does not charge properly, take the speaker

and USB cable to your local servicecenter.

3. You may charge a partially discharged battery whenever

you desire with no adverse effect on thespeaker

.

Important Safety Instructions for All

Integral Battery Charging



WARNING: Read all safety warnings, instructions,

and cautionary markings for the battery,

charging cable and product. Failure to follow the

warnings and instructions may result in electric

shock, fire and/or seriousinjury.



WARNING:

Only charge product using a Listed Class 2

USB power adapter that is compliant with applicable

country regulations and international/regional safety

standards. Using adapters that do not meet applicable

safety standards could result in injury.



WARNING: Do not charge the battery at ambient

temperatures below 40°F (4°C) or above 104°F

(40°C). Follow all charging instructions and do not

charge the battery outside of the temperature range

specified in the instructions. Charging improperly or

at temperatures outside of the specified range may

damage the battery and increase risk offire.

• Do not expose a battery to fire or excessive temperature.

Exposure to fire or temperature above 266°F (130°C) may

causeexplosion.

• Only use the charging cable supplied by the manufacturer

for charging.

• The provided charging cable is not intended for any

uses other than charging

DeWALT rechargeable tools

with

charging

ports. Charging other types of tools may

cause their batteries to overheat and burst, resulting in

personal injury, property damage, fire, electric shock

orelectrocution.

• DO NOT expose charging cable to water, rain orsnow.

• Pull by the plugs rather than the cord when

disconnecting the charging cable. This will reduce the

risk of damage to the plugs andcord.

• Make sure that the cord is located so that it will not

be stepped on, tripped over or otherwise subjected to

damage orstress.

• DO NOT use a charging cable with a damaged cord

orplugs. Have them replacedimmediately.

• Foreign materials of a conductive nature, such as, but

not limited to, grinding dust, metal chips, steel wool,

aluminum foil or any buildup of metallic particles

should be kept away from the charging plugs and port.

• Always unplug the charging cable from the power

supply when there is no tool attached toit.

BATTERIES

The product is not fully charged out of the carton. Before

using the product, read the safety instructions below and

then follow the charging proceduresoutlined.

nOTE: If the product is unused for approximately 90days,

fully charge the battery to help prolong the life of thebattery.

......................earthing terminal

.....................safety alert symbol

..................... visible radiation

do not stare into

the light

..................... wear eye protection

..................... wear hearing

protection

..................... r

ead all documentation

.....................

do not expose to rain
