12
EnGLIsh
Speed Mode Button (Fig.U)
The speed mode button
16
toggles between the three speed
settings: Auto Sense, Eco Mode, and Power Boost. Refer to
Adjusting Mower Speed (Fig. U) for additional information.
Starting Mower (Fig.R‑T)
DANGER: Sharp moving blade. Never attempt to
override the operation of the switch box and safety
key system as serious injury couldresult.
WARNING: Ensure self drive is disengaged before starting
themower.
nOTE: Mower is operational when the battery pack(s)
27
and
safety key
6
areinstalled.
1. Raise and adjust single touch handle
1
. Refer to Raise the
Single Touch Handle (Fig.D, E) and Adjusting the Main
Handle Height (Fig.F) on page 49.
2. Lift and hold the battery port cover
18
up to expose the
battery port
39
.
3. Slide a battery pack(s)
27
into the battery port
39
until an
audible click isheard.
nOTE: Ensure the battery pack(s) is fully seated and fully
latched intoposition before startingmower.
4. Close the battery port cover
18
. Ensure the battery port
cover
18
is fully closed before starting themower.
5. Insert safety key
6
into the key slot
40
, located on the main
handle
4
, until it is fully seated inside of the keyslot
40
as
shown in Fig. T.
6. To power on the control panel
12
, pull and hold the bail
handle
8
to the main handle
4
.
7. To start the mower blades, continue to hold the bail
handle
8
to the main handle
4
and then press the power
button
11
.
nOTE: Once the mower starts you can release the
power button
11
, but you must continue to hold the
bail handle
8
to themain handle
4
for the mower
tostayrunning.
8. To turn the mower OFF, release the bailhandle
8
.
WARNING: Never attempt to lock a switch or bail handle
in the ONposition.
nOTE: Once the bail handle
8
has returned to the original
position it will activate the “Automatic Braking Mechanism.”
The motor is braked and the mower blades will stop rotating in
three seconds orless. If mower blades rotate longer than three
seconds, discontinue using mower and have itserviced.
Adjusting Mower Speed (Fig. U)
The mower is equipped with a speed button
16
and speed
indicator
65
. The speed indicator
65
will display the chosen
speed of the mower. There are three speed setting LEDs,
Auto Sense
62
, Eco Mode
63
and Power Boost
64
. The speed
indicator
65
helps you to optimize the mower's performance
and runtime needed for each job.
1. To set the mower speed, switch the moweron as indicated
in Starting Mower.
2. Press the speed button
16
, located on the control panel,
until the desired speed LED is illuminated.
nOTE: Auto Sense mode
62
, Eco Mode
63
or Power Boost
mode
64
.
nOTE: The mower defaults to Auto Sense mode
62
.
3. Operate in Auto Sense mode
62
or Eco Mode
63
speed for
most mowing needs.
nOTE: Longer runtime will be achieved.
4. Choose Power Boost mode
64
as needed to clear
heavygrass.
nOTE: Runtime will be reduced.
Speed Setting LEDs
SPEED
Power Boost
Eco Mode
Auto Sense
Self Drive System (Fig.V)
DANGER: Sharp moving blade. Never attempt to
override the operation of the switch box, the self
drive system or the safety key system as serious
injury couldresult.
Your mower is equipped with a self drive system which functions
independently of the mowerblades.
1. To use self drive, press the self drive lever
9
towards the
main handle
4
.
2. To turn off self drive, release the self drive lever
9
.
nOTE: During cutting, at times it may be easier to maneuver
around an object, such as a tree or plants, with the self drive off.
The mower can easily be used with the selfdrivesystemoff.
Speed Adjustment Dial (Fig.W)
Your mower is equipped with a speed adjustment dial
10
located next to the control panel
12
. The numbers on the
speed adjustment dial
10
indicate how quickly or slowly the
self drive system propels themower. Choosing a lower number
propels themower at a slower pace. Choosing a higher number
propels themower at a fasterpace.
1. To increase the speed of the self drive system, rotate the
speed adjustment dial
10
towards the rabbit icon
41
.
nOTE: The speed adjustment dial
10
will display a
highernumber.
2. To decrease the speed of the self drive system, rotate the
speed adjustment dial
10
towards the turtle icon
42
.
nOTE: The speed adjustment dial
10
will display a
lowernumber.
