40
ENGLISH
Inserting and Removing the Battery Pack from the
Tool (Fig. A)
NOTE: Make sure your battery pack
27
is fullycharged.
To Install the Battery Pack into the ToolHandle
1. Align the battery pack with the rails inside the tool’s
handle(Fig. A).
Description (Fig. A)
WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
Powerhead
2
Pole assembly
3
Telescoping pole
4
Trigger switch
5
Lock off lever (DCMPS635)
6
Operator presence lever
7
Main handle
8
Speed control button/ Wake-up button
9
Battery state of charge LED
10
Overload indicator LED
Date Code Position (Fig.G)
The production date code
61
consists of a 4-digit year followed
by a 2-digit week and is extended by a 2-digit factorycode.
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual beforeuse.
Wear eyeprotection.
Wear earprotection.
Do not leave inrain.
Wear headprotection.
Wear protectivegloves.
Cut hazard. Keep fingers away fromslot.
Wear protectivefootwear.
Rotational direction of the sawchain.
Electrocution hazard. Keep at least 10 m
away from overheadlines.
Switch the tool off. Before performing any
maintenance on the tool, remove the battery
from thetool.
Directive 2000/14/EC guaranteed
soundpower.
Keep bystandersaway.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal injury,
turn tool off and disconnect battery pack before making any
adjustments or removing/installing attachments or accessories.
An accidental start-up can causeinjury.
WARNING:
Use only DeWALT batteries andchargers.
11
Speed indicator LEDs
12
Insulated hand grip
13
Threaded sleeve
14
Saw head
15
Guide bar
16
Saw chain
17
Sprocket cover
18
Bar lock nut
19
Chain tensioning screw
20
Branch removal hook
21
Oil level indicator
22
Oil cap
23
Scabbard
24
Wrench
25
Strap mount
26
Shoulder strap
27
Battery pack
†
28
Battery release button
29
4 mm round file
30
T20 wrench
†
Included in some packages.
NOTE: Check for damage to the tool, parts or accessories which
may have occurred during transport.
Intended Use
The DCMPS635, DCMPS640 have been designed for professional
and residential trimming applications. The DCMPS635is ideal
for pruning and cutting limbs up to 20cm (8") indiameter.
The DCMPS640 is ideal for pruning and cutting limbs up to
25cm(10") indiameter. The pole saw is not intended to be
operated in a tree, on a ladder, from any unstable support and
should always be operated with twohands.
DO NOT use under wet conditions, during heavy winds/storms,
or in presence of flammable liquids orgases.
DO NOT use in dark or foggy conditions. This tool is to be used
with sufficient light.
These pole saws are professional powertools.
DO NOT let children come into contact with the tool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or mental
abilities; lack of experience, knowledge or skills. Children should
never be left alone with thisproduct.
