ENGLISH
6
Repairs
The charger and batteries are notserviceable. There are no
serviceable parts inside the charger or batterypack.
WARNING: To assure product SAFETY and RELIABILITY,
repairs, maintenance and adjustment (including brush
inspection and replacement, when applicable) should be
performed by a factory service center or an authorized service
center. Always use identical replacementparts.
DeWALT Tool Connect™ Chip Ready (Fig. I)
Optional Accessory, Sold Separately
WARNING: Read instruction manual for the DeWALT
ToolConnect™ Chip.
WARNING: Remove battery from tool before installing the
DeWALT ToolConnect™ Chip.
WARNING: When installing or replacing the DeWALT
ToolConnect™ Chip, use only the screws provided. Be sure to
securely tighten thescrews.
Your product comes with a dedicated pocket
15
and
fasteners
16
for installing a DeWALT Tool Connect™ Chip.
The DeWALT Tool Connect™ Chip is designed for tracking
and locating professional power tools, equipment, machines,
and other assets with a DeWALT chip pocket using the
DeWALT Site Manager app.* For proper installation and
onboarding of the DeWALT Tool Connect™ Chip, refer to the
DeWALT Tool Connect™ Chipmanual.
To learn more,visit: www.DeWALT.com/en-us/
jobsite-solutions/tool-connect.
*The DEWALT Site Manager app is governed by separate
terms and conditions available for viewing through the
mobile or web application. Additional subscription charges
and third-party data charges may apply.
objects from the belt hook. ONLY hang tool’s belt hook
from a workbelt.
WARNING: To reduce the risk of serious personal
injury, ensure the screw holding the belt hook issecure.
CAUTION: To reduce the risk of personal injury or
damage, DO NOT use the belt hook to hang thetool.
IMPORTANT: When attaching or replacing the belt
hook
12
, use only the screw
13
that is provided. Be sure to
securely tightenscrew.
If the belt hook is not desired at all, it can be removed from
thetool.
1. Place the belt hook onto the accessory attachment
location
14
at the base of thetool.
2. Use a screwdriver to secure the belt hook with the
provided screw. Do not use any other screw forthis.
To remove the belt hook, remove the screwthat holds the
belt hook inplace.
NOTE: When using the belt hook, keep hands away from the
trigger switch
4
.
Belt Hook (Fig. A, H)
Optional accessory
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack before
making any adjustments or removing/installing
attachments oraccessories.
WARNING: To reduce the risk of serious personal
injury, DO NOT suspend tool overhead or suspend
Blade Replacement (Fig. F, G)
WARNING: Blade is sharp. Handle withcare.
WARNING: Before starting blade replacement procedure,
wear safety glasses, disconnect the tool from battery and set
the trigger lock button
5
in its locked state. Always rest the tool
flat on even surface during bladereplacement.
The blade
7
is secured in the gearcase with two set
screws
10
.
1. Use the provided #3 hex wrench
9
to unscrew the two
set screws and pull out blade
7
from itsslot.
NOTE: If the blade is stuck in slot, use a flat head screwdriver
or pair of needle nose pliers to removeblade.
2. Examine and clear any debris from theslot.
3. Insert a new blade into the holder slot. For proper
orientation of blade, ensure hole on blade lines up close with
the outer setscrew.
4. Use the provided hex wrench to screw in the two
set screws and secure blade in the tool. Alternately
tighten both screws to ensure correct blade alignment.
Avoid overtightening the set screws to prevent any
potentialdamage.
5. Ensure edges evenly stick out on both inner and outer
diameter deburringsides.
The tool is now ready touse.
Accessories
WARNING: Since accessories, other than those offered by
DeWALT, have not been tested with this product, use of such
accessories with this product could be hazardous. To reduce
the risk of injury, only DeWALT‑recommended accessories
should be used with thisproduct.
Recommended accessories for use with your product are
available at extra cost from your local dealer or authorized
service center. If you need assistance in locating any
accessory, please contact DeWALT. Call 1-800-4-DeWALT
(1-800-433-9258) or visit our website: www.dewalt.com.
Cleaning
WARNING: To prevent risk of injury, always remove blade
from tool before cleaning. Use dry cloth or wire brush to clean
air vents and remove shards of material from gearcase.
To
minimize the risk of eye injury, always wear ANSI Z87.1 approved
eye protection when perform
ing thisprocedure.
WARNING: To reduce the risk of eye injury, NEVER blow air
on or inside the gearcase to clean debris.
WARNING:
Never use solvents or other harsh chemicals
for cleaning the non‑metallic parts of the tool. These chemicals
may weaken the plastic materials used in these parts. Use a
cloth dampened only with water and mild soap. Never let any
liquid get inside the tool; never immerse any part of the tool into
aliquid.
Remove blade periodically to clean any debris from the slot.
Register Online
Thank you for your purchase. Register your product nowfor:
• WARRANTY SERVICE: Registering your product will help
you obtain more efficient warranty service in case there is a
problem with yourproduct.
• CONFIRMATION OF OWNERSHIP: In case of an insurance
loss, such as fire, flood or theft, your registration of ownership
will serve as your proof ofpurchase.
