Setting up the monitor 29
VESA wall mounting (optional)
Figure 22. VESA wall mounting
See the instructions that come with the VESA-compatible base mounting kit.
1. Place the monitor panel on a soft cloth or cushion on a stable flat table.
2. Remove the stand. For more information, see Removing the monitor stand.
3. Attach the mounting bracket from the wall mounting kit to the monitor.
4. Mount the monitor on the wall. For more information, see the documentation that is shipped with the wall mounting kit.
NOTE: Use M4x10 mm screws to connect the monitor to the wall-mounting kit (VESA screws are not included with the monitor).
For use only with UL or CSA listed wall-mount brackets that have a minimum weight/load-bearing capacity of 11.20 kg (24.69 lb).
Using tilt
You can tilt the monitor for the most comfortable viewing angle.
NOTE: The stand is not attached when the monitor is shipped from the factory.
5° 21°
Figure 23. Tilt adjustment
