Setting up the monitor
8. Lift the protective cover from the monitor.
Figure 22. Lift the protective cover from the monitor
Using the tilt, swivel, and height extension
NOTE: The following instructions are applicable only for the stand that is shipped with your monitor. If you are attaching a stand
that you purchased from any other source, follow the setup instructions that are included with the stand.
Tilt and swivel adjustment
With the stand that is attached to the monitor, you can tilt and swivel the monitor for the most comfortable viewing angle.
5°
30° 30°
21°
Figure 23. Tilt and swivel adjustment
NOTE: The stand is detached when the monitor is shipped from the factory.
Height adjustment
The stand extends vertically up to 150 mm. The following image illustrates how to extend the stand vertically.
150 mm
Figure 24. Height adjustment
