37
Setting up the monitor
Connecting the monitor for DPBS for the first time
Initial monitor power state(OFF)
Initial system power state(OFF)
USB-C
USB-C
Figure 42. Connecting the monitor for DPBS for the first time
Perform the following steps when setting up the DPBS function for the first time:
1. Navigate to Dell Power Button Sync in sub menu under Display and enable it.
2. Ensure both the monitor and computer are turned off.
3. Connect the USB-C cable from the computer to the monitor.
4. Press the monitor power button to turn on the monitor.
5. Both the monitor and computer turn on momentarily. If not, press the power button of the monitor or the computer to boot up
the system.
6. When you connect the Dell OptiPlex 7090/3090 Ultra platform, you may see both the monitor and computer turn on momentarily.
Wait for a while (approximately 6 seconds) and both the computer and monitor will turn OFF. When you press either the monitor
power button or the computer power button, both the computer and monitor turn ON. The computer system power state is in
sync with the monitor power button.
NOTE: When the monitor and computer are both at power OFF state at first time, it is recommended that you turn ON the
monitor first, then connect the USB-C cable from the computer to the monitor.
NOTE: You can power the Dell computer* Ultra platform using its DC adapter jack. Alternatively, you can power the Dell
computer* Ultra platform using the monitor’s USB-C cable via Power Delivery (PD); set USB-C Charging to On in Off Mode.
* Ensure to check the Dell computer for DPBS supportability.
