Display assembly
Removing the display assembly
CAUTION: The information in this removing section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the SIM card (optional).
3. Remove the base cover.
4. Remove the battery.
5. Remove the 5G WWAN card.
About this task
The following images indicate the location of the display assembly and provide a visual representation of the removal procedure.
Figure 45. Removing the display assembly
Removing and installing Field Replaceable Units (FRUs)
91
