Palm-rest assembly
Removing the palm-rest assembly
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
NOTE: Ensure that your computer is in Service Mode. For more information see, step 6 in Before working inside your
computer.
2. Remove the SD card.
3. Remove the base cover.
4. Remove the M.2 2230 solid state drive or M.2 2280 solid state drive.
5. Remove the battery.
6. Remove the display assembly.
7. Remove the processor fan.
8. Remove the graphics-card fan.
9. Remove the heatsink.
10. Remove the smart-card reader for systems shipped with a smart-card reader.
11. Remove the graphics card or dummy graphics card.
12. Remove the system board.
13. Remove the speakers.
14. Remove the WLAN antennas.
15. Remove the power button with fingerprint reader assembly.
About this task
The following images indicate the location of the palm-rest assembly and provide a visual representation of the removal
procedure.
116
Removing and installing Field Replaceable Units (FRUs)
