You can install the monitor in any Plug and Play-compatible system. The monitor automatically provides the computer system with its Extended Display Identification Data
(EDI D) using Display Data Channel (DDC) protocols so the system can configure itself and optimize the monitor settings. If desired, the user can select different settings, but in
most cases monitor installation is automatic.
Gen er al
Model number 1704FPV
Flat Panel
Screen type Active matrix - TFT LCD
Screen dimensions 17 inches (17-inch viewable image size)
Preset display area:
Horizontal 337 mm (13.3 inches)
Vertical 270 mm (10.6 inches)
Pixel pitch 0.264 m m
Viewing angle 178° (vertical) typ, 178° (horizontal) typ
Luminance output 280 CD/m ² (typ)
Contrast ratio 1000 to 1 (typ)
Faceplate coating Antiglare with hard- coating 3H
Backlight CCFL (4) edgelight system
Response Time 25ms typical
Resolut ion
Horizontal scan range 30 kHz to 81 kHz (automatic)
Vertical scan range 56
Hz to 76 Hz (automatic)
Optimal preset resolution 1280 x 1024 at 60 Hz
Highest preset resolution 1280 x 1024 at 75 Hz
Preset Display Modes
Display Mod e Horizont al Frequen cy ( k Hz) Vert ical Fr equency ( Hz) Pix el Clock ( MHz) Syn c Polar it y ( Hor izont al/ Vert ical)
VESA, 720 x 400 31.5 70.0 28.3 -/ +
VESA, 640 x 480 31.5 60.0 25.2 -/ -
VESA, 640 x 480 37.5 75.0 31.5 -/ -
VESA, 800 x 600 37.9 60.3 49.5 + /+
VESA, 800 x 600 46.9 75.0 49.5 + /+
VESA, 1024 x 768 48.4 60.0 65.0 -/ -
VESA, 1024 x 768 60.0 75.0 78.8 + /+
VESA, 1152 x 864 67.5 75.0 108 + /+
VESA, 1280 x 1024 64.0 60.0 135.0 + /+
VESA, 1280 x 1024 80.0 75.0 135.0 + /+
Elect rical
Video input signals Analog RGB, 0.7 Volts + / -5% , positive polarity at 75 ohm input impedance
Digital DVI -D TMDS, 600mV for each differential line, positive polarity at 50 ohm input
impedance
Synchronization input signals Separate horizontal and vertical synchronizations, polarity-free TTL level, SOG (Composite SYNC
