1 Video-Red
2 Video-Green
3 Video-Blue
4 GND
5 GND
6 GND-R
7 GND-G
8 GND-B
9 DDC + 5V
10 Sync/ self-test
11 GND
12 DDC data
13 H-sync
14 V- sync
15 DDC clock
24 pin digit al-only DVI con nect or :
Note: Pin 1 is at the top right.
Pin Signal Assignment Pin Signal Assignment Pin Signal Assignment
1 T.M.D.S. Data 2- 9 T.M.D.S. Data 1- 17 T.M.D.S. Data 0-
2 T.M.D.S. Data 2+ 10 T.M.D.S. Data 1+ 18 T.M.D.S. Data 0+
3 T.M.D.S. Data 2 Shield 11 T.M.D.S. Data 1 Shield 19 T.M.D.S. Data 0 Shield
4 No Pin 12 No Pin 20 No Pin
5 No Pin 13 No Pin 21 No Pin
6 DDC Clock 14 + 5V Power 22 T.M.D.S. Clock Shield
7 DDC Data 15 Ground (for + 5V) 23 T.M.D.S. Clock +
8 No Connect 16 Hot Plug Detect 24 T.M.D.S. Clock -
Univer sal Serial Bus ( USB) I nt erface
This monitor supports High-Speed Certified USB 2.0 interface.*
Data Rate Power Consumption
High speed 480 Mbps
2.5W (Max., each port)
Full speed 12 Mbps
2.5W (Max., each port)
Low speed 1.5 Mbps
2.5W (Max., each port)
USB port s:
1 upstream - rear
4 downstream - 2 on rear; 2 on left side
NOTE: USB 2.0 capab ilit y r equires 2.0 capable com pu t er
NOTE: Monitor 's USB in t erface w ork s ONLY w hen m onitor is Pow er ed ON ( or in Pow er Save Mode) . Sw it ch in g y our m onitor OFF an d t hen ON w ould r e-
enum er ate its USB int er face; at t ached per ipherals m ay t ak e a few seconds t o r esum e norm al fun ctionalit y .
Plug an d Play Capabilit y
