24 Part Number: 9291458 11/17
Installation Section 2
Electrical Service
DANGER
Check all wiring connections, including factory
terminals, before operation. Connections can become
loose during shipment and installation.
n
Warning
This appliance must be grounded and all field wiring
must conform to all applicable local and national
codes. Refer to rating plate for proper voltage. It is the
responsibility of the end user to provide the disconnect
means to satisfy the authority having jurisdiction.
VOLTAGE
All electrical work, including wire routing and grounding,
must conform to local, state and national electrical codes.
The following precautions must be observed:
• The equipment must be grounded.
• A separate fuse/circuit breaker must be provided for
each unit.
• A qualified electrician must determine proper wire size
dependent upon location, materials used and length
of run (minimum circuit ampacity can be used to help
select the wire size).
• The maximum allowable voltage variation is ±10% of
the rated voltage at equipment start-up (when the
electrical load is highest).
• Check all green ground screws, cables and wire
connections to verify they are tight before start-up.
GROUND FAULT CIRCUIT INTERRUPTER
Ground Fault Circuit Interrupter (GFCI/GFI) protection is
a system that shuts down the electric circuit (opens it)
when it senses an unexpected loss of power, presumably
to ground. Manitowoc does not recommend the use of
GFCI/GFI circuit protection to energize our equipment. If
code requires the use of a GFCI/GFI then you must follow
the local code. The circuit must be dedicated, sized
properly and there must be a panel GFCI/GFI breaker. We
do not recommend the use of GFCI/GFI outlets to energize
our equipment as they are known for more intermittent
nuisance trips than panel breakers.
RATED AMPERAGES, HORSEPOWER, VOLTAGE &
POWER CORD CHART
Units with plugs are supplied with approximately 6ft
(183cm) cords.
Model V, Hz, Ph Amps H.P. Plug
8100-EF Series
8118-EF 115, 60, 1 7.5 1/4 NEMA 5-15P
8132-EF 115, 60, 1 7.5 1/4 NEMA 5-15P
8145-EF 115, 60, 1 7.5 1/4 NEMA 5-15P
8159-EF 115, 60, 1 7.5 1/4 NEMA 5-15P
8172-EF 115, 60, 1 7.5 1/4 NEMA 5-15P
8186-EF 115, 60, 1 8 1/3 NEMA 5-15P
8100-EF-E Export Series
8118-EF-E
230-240, 50, 1
2.5 Amps /
600 Watts
1/4
Varies Per
Destination
8132-EF-E
8145-EF-E
8159-EF-E
8172-EF-E
8186-EF-E
8100-EFN Series
8148-EFN
115, 60, 1 7.5 1/4 NEMA 5-15P8169-EFN
8191-EFN
8100-EFN-E Export Series
8148-EFN-E
230-240, 50, 1
2.5 Amps /
600 Watts
1/4
Varies Per
Destination
8169-EFN-E
8191-EFN-E
N8000 Series - NA
N8000N Series - NA
N8000-R Series - NA
N8100B Series
N8118B 115, 60, 1 3.7 1/5 NEMA 5-15P
N8130B 115, 60, 1 3.7 1/5 NEMA 5-15P
N8143B 115, 60, 1 3.7 1/5 NEMA 5-15P
N8156B 115, 60, 1 5.6 1/4 NEMA 5-15P
N8169B 115, 60, 1 5.6 1/4 NEMA 5-15P
N8181B 115, 60, 1 7.3 1/3 NEMA 5-15P
N8100B-E Export Series - R404A
N8118B-E
230-240, 50, 1
1.5 Amps /
360 Watts
1/5
Varies Per
Destination
N8130B-E
N8143B-E
N8100B-E Export Series - R134A
N8156B-E
230-240, 50, 1
2.5 Amps /
600 Watts
1/4
Varies Per
Destination
N8169B-E
N8100BR Series
N8144-BR 115, 60, 1 4.0 1/5 NEMA 5-15P
N8159-BR 115, 60, 1 7.0 1/4 NEMA 5-15P
N8176-BR 115, 60, 1 7.3 1/3 NEMA 5-15P
N8194-BR 115, 60, 1 8.0 1/3 NEMA 5-15P
N8100-FA Series
N8131-FA 115, 60, 1 7.8 1/4 NEMA 5-15P
N8144-FA 115, 60, 1 9.2 1/2 NEMA 5-15P
N8157-FA 115, 60, 1 9.2 1/2 NEMA 5-15P
N8169-FA 115, 60, 1 14.8 3/4 NEMA 5-20P
N8182-FA 115, 60, 1 14.8 3/4 NEMA 5-20P
N8100NB Series
N8146NB 115, 60, 1 3.7 1/5 NEMA 5-15P
N8168NB 115, 60, 1 5.6 1/4 NEMA 5-15P
