32 Part Number: 9294997A 09/21
Operation Section 3
Mobile Application
SPECIFICATION LINE CONNECT
This mobile application is an equipment
monitoring tool.
To Download The Mobile Application:
1. Open either Apple iTunes or Google PlayStore.
2. Search for Specification Line Connect.
3. Select and install.
4. Open the application. The Welbilt W logo is the
application icon.
Application Operation
Set Up A Site
1. Select + Add Site.
2. Fill in all site information. All fields are required.
₋ Site ID (Max 30 Characters)
₋ Site Name (Max 20 Characters)
₋ Site Manager Name (Max 20 Characters)
₋ Site Email ID (Max 50 Characters)
₋ Site Address (Max 50 Characters)
₋ Country (From a Menu)
₋ State (From a Menu
₋ City (Max 20 Characters)
₋ Postal Code (Max 10
Characters)
3. Select Choose Site Location
to put a pin on the map.
4. Select Submit.
5. The new site will be added to the home page.
Edit Or Delete Site
1. Select the menu icon next to
the site.
2. Edit and Delete Site are
available actions.
3. Edit will bring up the site
information page.
4. Delete will require confirmation.
Set Up Equipment
1. Select the menu icon next to the site.
2. Select View Equipments.
3. Select + Add.
4. Fill in all equipment information. All fields are required.
NOTE: Serial number entered must match equipment.
₋ Equipment Serial Number (Max 30 Characters)
₋ Equipment Name (Max 20 Characters)
₋ Equipment Type (From a Menu)
₋ Equipment Model (From a Menu)
5. Select Submit.
6. The new equipment will be connected to the site.
Edit Or Delete Equipment
1. Select the menu icon next to the
equipment.
2. Edit and Delete Equipment are
available actions.
3. Edit will bring up the equipment
information page.
4. Delete will require confirmation.
EQUIPMENT MANAGEMENT
Converting .csv file to useable Excel file:
Highlight Column A
Go to the Data tab
- Under the Data Tools group, select Text to Columns
In the Convert Text to Column wizard, choose the Delimited
file type and click next
- Select tab and comma, click next, and click finish
View Equipment Statistics
Tabs include:
• Summary tab includes the following statistics:
₋ Cavity1 Temp Max/Min
₋ Cavity2 Temp Max/Min
₋ Ambient Temp Max/Min
₋ Energy Used
₋ Network
₋ Signal Strength
• Latest Temperature Information
• Set Point Vs Cavity Vs Ambient Temperature
• Condenser Inlet Vs Outlet Temperature
• Evaporator Inlet Vs Outlet Temperature
