Page 12
Gas Jet Cleaning Procedure
• The gas jets on your hob should be cleaned
every 6 months.
• This may be done using a Gas Jet Cleaning
Kit which may be purchased from your
nearest Defy Service Centre.
• The kit comprises of a sliding T-bar (A) a
socket (B) and a ‘Classic pin’ (C).
• Fit the T-bar to the socket and remove the
pot stands, burner caps and burner
bodies.
1. Insert the socket into the central tube of the
burner so that it locates over the brass gas jet
at the bottom of the tube.
2. Gently loosen the brass gas jet by turning the
socket in an anti-clockwise direction.
3. Carefully lift the socket and loosened brass
gas jet from the central burner tube.
4. Insert the Classic pin into central hole of the
jet and slide it up and down until the jet is free
of accumulated dirt.
5. Re-assemble in reverse order.
Removing the Oven Door Glass
A. Press clips on both ends of the top décor.
B. Lift the top décor & remove from door.
C. Lift the glass to a 45 degree position and pull
towards yourself.
Do not use any harsh abrasive
cleaners, hard metal scrapers,
scouring pads or bleach to clean the
front door inner glass as they may
scratch the surface and destroy the
coating material.
These steps should be carried out in
reverse order to install the door. Do
not forget to close the clips at the
hinge housing when reinstalling.
Removing the oven door
The oven door may be removed to improve oven
access during cleaning.
1. Open the front door (1).
2. Push down the clips at the hinge housing (2)
on the left and right hand sides of the front
door by pressing them down as illustrated in
the figure.
A
B
3. Open the door to halfway.
4. Remove the door by pulling it upwards to
release it from the hinges.
