34
6. Preparing for use
The device is part of the SAS+ALL line, so to use
it, a kit consisting of the device, battery and
charger must be completed. The use of other batteries and chargers
is prohibited.
All operations described in this chapter should be
carried out with the battery disconnected.
After removal from the box, the unit can be used immediately and
requires no further preparation.
7. Switching on the device
Przed uruchomieniem urządzenia bezwzględnie
wykonać czynności opisane w rozdziale
„Przygotowanie do pracy”.
Slide the battery pack from the SAS+ALL line into the slot (Fig. A, 7) and
push it in until it locks into place. To remove the battery, release the
locking latch and slide the battery out of the socket.
To switch on the appliance, press the on/off button (Fig. A, 2). Releasing
the switch button will switch the unit off.
8. Operation of the device
If the battery gets hotter than 40°C, stop operation
and wait for the battery to cool down.
When operating the device, all safety rules and
instructions described in the safety conditions
must be strictly observed..
Fill the hopper with the correct amount of spreading material.
When spreading seed or applying fertiliser, always pay attention to the
dosage specified by the manufacturer.
Three adjustment elements are used to adjust the application rate:
- a knob to regulate the amount of material to be applied (Fig. A, 3). With
the machine switched off, turn the knob. This will change the size of the
material feed opening, thereby increasing (or decreasing) the amount of
material fed.
- Material ejection radius change lever (Fig. A, 5). Changing the position
of the lever will change the material ejection radius, thereby increasing
(or decreasing) the material feed range.
- Speed change knob (Fig. A, 6). Changing the position on the knob will
make the material feed faster (or slower).
Once the material feeding parameters have been set, start the machine
with the switch (Fig. A, 2) and spread the material evenly over the surface
(e.g. lawns, flowerbeds, pavements, etc.).
9. Ongoing maintenance
All maintenance must be carried out with the unit
unplugged.
Clean the entire power tool regularly, paying particular attention to
cleaning the ventilation openings of the power tool.
Avoid charging the battery pack immediately after intensive use. Due to
the discharge phenomenon, do not store the battery pack completely
discharged, as it may then discharge below a critical level and become
permanently damaged.
Therefore, when not in use, the battery should be stored partially charged
(to approx. 40%). The battery should be charged before it is completely
discharged. Batteries should be stored at a temperature of 10-30°C.
Batteries stored at low temperatures lose capacity more quickly.
For how to charge the battery pack, refer to the instructions for the battery
pack and charger in the SAS+ALL series.
Keep the device out of the reach of children.
If it is necessary to send the device to a service centre for repair, protect
it from accidental mechanical damage and remove the batteries from the
charger socket.
How to dismantle the battery
To remove the battery pack, grasp the unit by the handle and then press
the release button on the front of the battery pack. Slide the battery pack
out of the socket. To fit the battery pack, slide the battery pack into the
battery slot and then press down until the handle latch engages.
Attachment, tool replacement
Once the tool has been clamped, make sure it has been clamped
correctly: lay the power tool horizontally and try to eject the clamped tip.
If it cannot be ejected, it means that it has been clamped correctly.
Maintenance of the appliance
Maintenance includes servicing of the equipment including accessories,
i.e. the battery and charger..
Never carry out maintenance work on equipment
that is connected to a power source.
This can cause serious injury or electric shock. The battery must be
removed from the battery socket before maintenance.
Maintenance of the unit consists of keeping all its components necessary
for normal operation properly clean. No solvents may be used for
cleaning as this may cause irreparable damage to the casing and other
plastic components.
The battery must not be cleaned with water as this may cause internal
short circuits leading to permanent damage.
Before each start-up:
- Check that the engine vents are not obstructed or dirty. If necessary,
expose/clean with a cloth slightly dampened with water.;
After each use:
- Disconnect the battery to avoid accidental activation by unauthorised
persons or during handling.
10. Spare parts and accessories
For the purchase of spare parts and accessories, please contact the
Dedra Exim service. Contact details can be found on page 1 of the
manual.
When ordering spare parts, please quote the batch number on the
nameplate together with the part number from the assembly drawing.
During the warranty period, repairs are carried out in accordance with the
terms of the warranty card. Return the faulty product for repair at the
place of purchase (the dealer is obliged to accept the faulty product),
send it to the central Dedra Exim service centre or to the service centre
closest to your place of residence (list of service centres at
www.dedra.pl). Kindly enclose the completed warranty card. After the
warranty period has expired, repairs are carried out by the central
service. Send the defective product to the service centre (shipping costs
are paid by the user).
11. Trouble-shooting on your own
Disconnect the unit from the power supply before
attempting to troubleshoot the unit yourself.
Problem
Cause
Solution
Device does
not work
Defective switch
Have the unit serviced
Battery discharged
Recharge the battery
Battery pack incorrectly
mounted
Fit correctly
Unit starts with
difficulty
Battery pack discharged
Charge the battery pack
correctly
Operating parameters
exceeded
Reduce the load on the
power tool
Motor
overheats
Ventilation openings
clogged
Clean holes
Operating parameters
exceeded
Switch off power tool,
postpone work until it has
cooled down completely
Outlet blocked
Check and unblock the
material outlet
12. Contents of the package
Cordless seed spreader - 1
13 Information for users on the disposal of electrical
and electronic equipment (applicable to households)
The symbol on the products or accompanying documentation
indicates that defective electrical or electronic equipment must not
be disposed of with household waste. If you need to dispose of,
reuse or recover components, take them to a specialist collection
point where they will be accepted free of charge. Information on the
location of collection points for used equipment is provided by local
authorities, e.g. on their websites.
By disposing of the appliance correctly, you will save valuable resources
and avoid negative effects on health and the environment due to the
possible presence of hazardous substances, mixtures and components
in the appliance.
Incorrect waste disposal is subject to penalties according to the relevant
local regulations.
Users in EU countries: If you need to dispose of electrical or electronic
equipment, please contact your nearest point of sale or supplier, who will
be able to provide further information.
Disposal in non-EU countries: This symbol only applies to countries
within the European Union. If you wish to dispose of this product, please
contact your local authorities or dealer for the correct method of disposal.
In accordance with Regulation (EU) 2023/1542 of the European
Parliament and of the Council on batteries and accumulators and waste
batteries and accumulators, defective or used batteries/accumulators
