36
of spoil when drilling, removal of chips when working with handheld tools
for sawing, drilling or other woodworking, etc.).
In addition, the hoover is equipped with a flexible hose with
interchangeable nozzles, allowing virtually any power tool to be
connected to the hoover. The removal of the hose end is illustrated in
Fig. B. Procedure when changing the hose end:
1. with a flat, narrow tool (e.g. a screwdriver), push in the lock marked 1.
2. pull the nozzle vigorously off the ring with the locking device (2).
3. insert the bit into the power tool so that the holes in the bit line up with
the lock on the ring (3).
4. press the bit until you hear the locks snap into place. Ensure that the
tip is correctly applied and that the locks in both holes are closed.
Filter shaker function
There is a filter shaker button on the engine cover. The button allows the
filter to be cleaned during operation. To clean the filter, plug (e.g. with
your hand) the air inlet in the flexible hose and press the flter button. You
can also press the button with the end of the flexible hose so that the
button closes the air inlet in the flexible hose.
10. Ongoing maintenance
All maintenance must be carried out with the unit
unplugged.
1. Unplug the power cord from the mains socket.
2. Release the hoover lid locks by pulling the catches off the hoover lid.
3. Remove the lid from the hoover tank.
4. Carefully, evenly slide the filter off the filter basket
5. Clean the filter with compressed air, shaking off collected dirt. If
necessary, rinse it under a stream of water (after cleaning it thoroughly).
6. After rinsing, leave the filter to dry freely (do not heat, dry with a hair
dryer, do not expose to sunlight).
7. After drying, place the filter on the cover of the water intake shut-off
valve. Care should be taken to ensure that the filter is fitted correctly.
The sponge filter should, after thorough cleaning, be rinsed under a jet of
water. Allow to dry freely.
Shake out the fabric bag, rinse under a stream of water after cleaning
thoroughly. Allow to dry freely.
Storage
Store the cleaned, thoroughly dried hoover in the original box in a dry
place, out of the reach of children and bystanders.
Clean the entire power tool regularly, paying particular attention to
cleaning the ventilation openings of the power tool.
11. Spare parts and accessories
For the purchase of spare parts and accessories, please contact the
Dedra Exim service. Contact details can be found on page 1 of the
manual.
When ordering spare parts, please quote the batch number on the
nameplate together with the part number from the assembly drawing.
During the warranty period, repairs are carried out in accordance with the
terms of the warranty card. Return the faulty product for repair at the
place of purchase (the dealer is obliged to accept the faulty product),
send it to the central Dedra Exim service centre or to the service centre
closest to your place of residence (list of service centres at
www.dedra.pl). Kindly enclose the completed warranty card. After the
warranty period has expired, repairs are carried out by the central
service. Send the defective product to the service centre (shipping costs
are paid by the user).
12. Trouble-shooting on your own
Disconnect the unit from the power supply before
attempting to troubleshoot the unit yourself.
PROBLEM
CAUSE
SOLUTION
Device does not switch
on
Incorrectly connected
power supply cable.
Carefully push the
power plug into the
socket
Unit does not switch on
Damaged power
supply cable.
Have the appliance
serviced
Unit does not switch on
No voltage.
Check the mains fuse.
Unit does not switch on
Defective switch.
Have the unit serviced.
Motor overheats,
suction power reduced.
Clogged air vents.
Clean the ventilation
openings.
Motor overheats,
suction power reduced.
Plugged flexible hose
or suction nozzle.
Remove blockage.
Motor overheats,
suction power reduced.
Clogged filter cover,
heavily soiled filter.
Check and clean the
filter.
Motor overheats,
suction power reduced.
Tank overfilled.
Empty the dirt
container.
Motor starts with
difficulty.
Clogged motor
bearings, dirty motor
fan.
Send the unit for
service.
13. Contents of the package
1) Vacuum cleaner - 1 item, 2) Suction hose - 1 item, 3) Telescopic
extension tube - 1 item, 4) Flat brush - 1 item, 5) Narrow brush - 1 item,
7) Tyou HEPA filter - 1 item, 8) Foam cover - 1 item, 9) Fabric bag - 3
items. Round brush - 1 item, 11. 11. power tool adapter - 1 unit.
14 Information for users on the disposal of electrical
and electronic equipment (applicable to households)
The symbol on the products or accompanying documentation
indicates that defective electrical or electronic equipment must not
be disposed of with household waste. If you need to dispose of,
reuse or recover components, take them to a specialist collection
point where they will be accepted free of charge. Information on the
location of collection points for used equipment is provided by local
authorities, e.g. on their websites.
By disposing of the appliance correctly, you will save valuable resources
and avoid negative effects on health and the environment due to the
possible presence of hazardous substances, mixtures and components
in the appliance.
Incorrect waste disposal is subject to penalties according to the relevant
local regulations.
Users in EU countries: If you need to dispose of electrical or electronic
equipment, please contact your nearest point of sale or supplier, who will
be able to provide further information.
Disposal in non-EU countries: This symbol only applies to countries
within the European Union. If you wish to dispose of this product, please
contact your local authorities or dealer for the correct method of disposal.
Warranty
for
……………….……………………………
(product name)
Catalogue No: ………………. Lot No.: ..........................
(hereinafter called the product)
Product purchase date : .............
Seller’s stamp
Date and seller’s signature: .................................
User’s statement:
I confirm that I have been informed about the warranty conditions and
the consequences of non-compliance with the guidelines in the
Operating Instructions and the warranty. I am aware of the conditions of
this warranty, which I confirm with my handwritten signature:
........................ ...............................
Date and place User’s signature
I. Product liability
1. The Warrantor - Dedra Exim Sp. z o.o. with its registered office in
Pruszków, address: ul. 3 Maja 8, 05-800 Pruszków, KRS
0000062517, District Court for the City of Warsaw in Warsaw, 14th
Economic Division of the National Court Register, TIN 527-020-49-
33, share capital: PLN 100,980.00.
2. The Warrantor provides the warranty for the Product from the
Warrantor 's distribution on the terms set out in this warranty.
3. Liability under the warranty shall only cover defects arising from
causes inherent in the Product at the time of delivery to the User.
4. By virtue of the warranty, the User obtains the right to have the
Product repaired free of charge, provided that the defect became
apparent during the warranty period. The method of repair of the
Product is at the discretion of the Warrantor. If the Warrantor finds
the repair impossible, the Warrantor reserves the right to replace the
defective element or the whole Product for a defect-free one, reduce
the price of the Product, or withdraw from the contract.
5. In relation to the User, who is not a consumer within the meaning of
the Act of April 23, 1964 on Civil Code, the Warrantor's liability for
damages resulting from this warranty and/or in connection with its
conclusion and performance, regardless of the legal title, is limited to
the maximum of the value of the defective Product.
II. Warranty period
Product components
Duration of warranty protection
DED6615
36 months from the date of purchase of the
Product as shown on this warranty card
Accessories
No warranty
