Application of connectors and controls

Connection of terminals

1. CH 1-2 – FREQ – high pass or low pass ﬁlter frequency adjustment (40 - 400 Hz at 12 dB / Oct)

2. CH 1-2 – CROSSOVER – selection of built-in ﬁlters operating mode (HPF, FLAT, LPF)

3. CH 1-2 – GAIN – input signal level adjustment (0.4 V – 8 V)

4. CH 3-4 – GAIN – input signal level adjustment (0.4 V – 8 V)

INP UT

CH3CH1

CH4CH2

GAI N HPF

50H z 12K Hz

HPF FLAT L PF/BP

CRO SSOVE R LPF

50H z1 2KHz

GAI N

Min Max

HPF

50H z 12K Hz

HPF FLAT L PF/BP

CRO SSOVE R LPF

50H z 12K Hz

Min Max

CH 1- 2 CH 3- 4

PROT ECT

CLIP

POWE R

POW ER INPU T

+12 V GNDREM I N

SPE AKERS O UTPUT S

BRI DGE

CH1 CH2

CH3 CH 4

1 3 4 5 6 7 8 9 10 11 12 13 14 15

1 2 3 4 5 76

8 9

10 11 12 13

5. CH 3-4 – CROSSOVER – selection of built-in ﬁlters operating mode (HPF, FLAT, LPF)

6. CH 3-4 – FREQ – high pass or low pass ﬁlter frequency adjustment (40 - 400 Hz at 12 dB / Oct)

Standard wiring diagram of four-channel ampliﬁer to head unit

Step 1. Connect one end of the RCA cable to the RCA output terminals at the HU and the second end to the ampliﬁer

RCA inputs terminals marked with CH1/CH2, CH3/CH4.

HPF

1 2 3 4 5 76

8 9

10 11 12 13

1 2
