5. INPUT – signal input, RCA jacks

6. GAIN CH 1-2 – input signal level adjustment (0.2 V – 6 V)

7. HPF CH 1-2 – high pass filter (10 Hz – 1 200 Hz / 100 Hz – 12 000 Hz at 12 dB/Oct)

8. CROSSOVER CH 1-2 – selection of built-in filters operating mode (HPF, FLAT, LPF/BP)

9. LPF CH 1-2 – low pass filter (50 Hz – 1 200 Hz / 500 Hz – 12 000 Hz at 12 dB/Oct)

10. CLIP CH 1-2 – LED on the clip (orange)

11. POWER – LED for operation (blue)

12. PROTECT – LED for protection (red)

13. GAIN CH 3-4 – input signal level adjustment (0.2 V – 6 V)

14. HPF CH 3-4 – high pass filter (10 Hz – 1 200 Hz / 100 Hz – 12 000 Hz at 12 dB/Oct)

15. CROSSOVER CH 3-4 – selection of built-in filters operating mode (HPF, FLAT, LPF/BP)

16. LPF CH 3-4 – low pass filter (50 Hz – 1 200 Hz / 500 Hz – 12 000 Hz at 12 dB/Oct

17. CLIP CH 3-4 – LED on the clip (orange)

18. input for connection of the bass remote controlREMOTE –

6 7 8 9 10

13 1814 15 16
