• 1USE
Quick switch-off alternat
ives :
i) If
user
keep
finger
on
the
selection
sensor for 2 seconds, the related zone
will be switched off.
ii) When you press touch keys and
(4/5) simultaneously, the hot plate
will switch off quickly.
RESIDUAL HEAT INDICATOR
The power indicator of the hot plate will
display an H when the glass surface
reaches a temperature that could
cause burning.
When this risk disappears,
i) the display switches off (if the device
is in stand by),
ii) or displays 0 (if the appliance is still
running).
Warning:
In a first run, H indication may appear
in a short time on the power display.
This showing is related with setup
operation and it does not mean the
cooking zone is hot.
Warning:
H indication is used for the safety
purposes in any case. Even if the
power is cut off for a long time, after
power on, H indication appears.
SWITCHING OFF THE DEVICE
The device can be switched off at any
time by pressing the general on/off
touch key (1). In standby mode an
H will appear in the zones that are hot.
The rest of the displays will not light up.
Locking of the touch keys
of the cooking hob
To prevent undesired manipulation you
can lock the entire unit, except for the
on/off touch key, using the locking touch
key (6). This function is useful for
child safety. When the lock is activated,
the lock indicator light (7) comes on.
However, even when the lock function
is activated on the swtiched on hob,
the on/off (1) touch key can be
used to switch off the hob.
On the other hand, if the touch control
is switched off, the lock function does
not allow the on/off touch key (1) to
be used.
To deactivate this function, press the
locking touch key (6) once again for
at least 3 seconds. Then the lock
indicator (7) lights off and the touch
controls will be ready for use.
CHILD LOCK
The child lock is different and more
complicated than key lock. User can
activate key lock via one sensor. But
child lock need a sensor sequence.
The Child Lock is being used to
prevent children from turning on the
hob.
Activating Child Lock :
1. The hob is switched on via (1) On/
Off touch key,
2. Any zone should not be selected.
When any zone is
not selected,
touch simultaneously the increase
power key (5) and the decrease
power key (4) for 3 seconds. At
the end of this period, a short buzzer
sound will be heard.
3. After buzzer signal ,touch the
locking touch key (there is no
need to keep press for a long time)
and a long buzzer sound is heard
and the Child Lock will be activated
and all power display shows “L”.
During Child Lock, if user touch any
sensor (Main sensor included) , “L” will
flash on display.
Warning : Child lock status
is not being
stored. If the energy of the hob is butted,
child lock status could not be preserved.
Deactivating Child Lock :
To be able to deactivate Child Lock, the
Child Lock should be activated before
and all power display show “L”
1. Touch simultaneously the
increase power key (5) and the
decrease power key (4) for 3
seconds until you hear a short
buzzer sound.
2. After the buzzer signal, touch the
locking touch key (there is no need
to keep press for a long time) and a
short buzzer sound will be heard
and the Child Lock will be
deactivated and the indicator will be
light off.
Preheat function
This function facilitates cooking as
you do not need to be present while it
is being done. The touch control pre-
programmes the chosen hot plate at
the maximum power and subsequently
lowers it to the desired power level
(which you have selected) after an
approximate amount of time (see
table 1).
Table 1
Selected
Power
Time of the
preheat function
(in minutes)
00
11
32
53
74
59
63
74
85
9-
VitroTech Function
The VitroTech function makes it possible to
pair two independent cooking zones to
have a larger cooking area to
accommodate all types of pans or pots.
SWITCHING ON Bridge Function
1.Press 2c and 2d at the same time
min
2sec.
When the VitroTech function will be
activated, VitroTech zone indicators light on.
2.Select the desired power (from 1 to 9)
using the touch key or (4/5).
SWITCHING OFF VitroTech Function
1.Press 2c or 2d or 2c and 2d at the same time
min 2sec.
When the VitroTech function will be deactivated,
VitroTech zone indicators light off.
15
