Je bekijkt pagina 36 van 44
10
INSTALLATION
• 1
By means of a straight spanner
L
nscrew the nozzle
U
and substitute it
with the corresponding one.
- Replace them with injectors for the
gas to be used, as shown in the gas
characteristics table (1.5);
- Thoroughly engage the key on the
injector.
- Strongly block the injectors.
Double crown burner: (1.4.2)
- Unscrew the screws (V) and remove
the cover (C);
- Unscrew the injector with a English
wrench (L)
- Fit the corresponding gas injectors (U)
instead, in accordance with the marking
of the injectors and the gas characteri-
stics table.
- Block the injectors vigorously.
- Fit the cover (C) and tighten the screws
(V).
Do not go beyond this limit; you
could to damage the product.
- Re-fit the burner heads, caps and pan
supports.
Every time you change the type
of gas used, tick the appropriate box
on the label in the wallet. Refer to
the "corresponding gas connection“
paragraph
3) Set the retarders on the taps:
ceux-ci sont situés sous les manettes
A
(1.4.3).
- Adjust each tap in turn
C
- Remove the knobs
A
, and sealing
washers
B
by pulling them upwards.
— Changing from natural gas to
butane/propane:
- Insert a flat-tipped screwdriver C into
the hole in the control panel and turn
the by-pass screw
F
(1.4.5), and, for
correct minimum setting, turn the screw
clockwise.
As regards G30 gas burners, the
by-pass screw must be tightened
completely.
The setting of the minimum must
always be correct and the flame must
always remain on even if the position is
changed from maximum to minimum.
— Changing from butane/propane to
natural gas:
- Loosen the adjusting screws in the
brass retarders (yellow) (1.4.5), using a
small, flat screwdriver, by 2 turns anti-
clockwise (1.4.5.2).
- Refit the knob,
- Light the burner in the maximum
position and then move to the low
position.
- Remove the knob again , then turn the
adjusting screw clockwise as far as the
lowest possible position before the flame
goes out.
- Re-fit the sealing washer and the knob.
- Move the knob from maximum to
minimum a few times: the flame
should not go out; if it does, loosen the
adjustment screw so that the flame stays
alight during these movements.
1•5 - GAS PROPERTIES :
The table (1.5) shows the installation
of the injectors on your appliance
depending on the gas used. Each
number is marked on the injector.
