Je bekijkt pagina 35 van 44
9
INSTALLATION
• 1
1
Connection via a flexible metal
hose (stainless steel) with screw
connectors (meeting standard NF D
36-121); the life of such hoses is not
limited.
2
Connection with a flexible
reinforced rubber hose with
mechanical screw connectors
(meeting standard NF D 36-103) with a
10-year life.
When connecting the gas to your
hob, if you have to change the direction
of the elbow fitted into the appliance:
• Change the seal.
• Tighten the nut on the elbow ensuring
that you do not exceed a tightening
torque of 17 N.m.
• Gas supplied from a cylinder or
tank (butane/propane gas) (1.3.2). For
your safety, you must choose only one of
the following three connections:
1
Connection via a rigid copper pipe
with mechanical screw connectors (½"
gas standard). Connect directly to the
elbow on the appliance.
2
Connection with a flexible metal
hose (stainless steel) with screw
connectors (to standard NF D 36-125);
the life of such hoses is not limited).
3
Connection with a reinforced
flexible rubber hose with mechanical
screw connectors (meeting standard
NF D 36-112) with a 10-year life.)
In an existing installation, a flexible hose
fitted
C
with jubilee clips (meeting
standard XP D 36-110) whose service
life is limited to 5 years may be used).
In this case an end connector must be
used with a sealing washer
A
fitted
between the end connector
B
and the
elbow on the hob.
You can purchase the end
connector and the sealing washer from
your after-sales department.
Tighten the end connector to a
torque not exceeding 25 N.m.
1•4 - CHANGING THE TYPE OF GAS:
Your appliance is supplied ready
for use with natural gas.
The injectors required for adapting
it to butane/propane can be found in
the plastic bag containing this guide.
Whenever you change the gas type, you
must follow these steps in turn:
1. Change the gas connection,
2. Change the injectors,
3. Adjust the retarder on the taps.
1) To change the gas connection :
- refer to the "Gas connection“
paragraph.
2) Change the injectors, proceeding as
follows:
- Remove all the supports, burner caps
and heads.
- completely insert the "straight pipe" key
L
key on the injector
U
. (1.4.1)
