FMX MONITOR

Code 420120314 REV. 1.2

POWER SUPPLY UNIT SECTION

6. POWER OFF

On/off switch.

7. VDE SOCKET

It allows the insertion of the cable with VDE connector.

WARNING!

• The connectors of this section are also used as power switches.

• Do not obstruct the rear heat sinks of the amplier. If the module heats up excessively,

the audio volume is gradually reduced until the module is thermally stabilized. The audio

is automatically restored when the normal operating temperature is reached.

• In the event of a malfunction, remove power supply immediately and disconnect the

module from the power mains. Contact an authorised repair centre.

• Never attempt to disassemble the amplier in any way.

• Only use cables with original, high quality Neutrik® connectors. Periodically check their

integrity.

8. FUSE HOUSING

Housing for the fuse.
