DATEQ SPL6 manual Network installation
7
Signaling connector;
DB-25 female
Pin Function In/ output
1 External attenuator In
2 Reduction signal Out; 15V/ 5mA max.
3 Overload signal Out; 15V/ 5mA max.
4 Live OK signal Out; 15V/ 5mA max.
5 Warning signal Out; 15V/ 5mA max.
6 Level OK signal Out; 15V/ 5mA max.
7 Safe level signal Out; 15V/ 5mA max.
8 External VU unit In/ Out
9 Microphone + In
10 Left audio in + In
11 Right audio in + In
12 Left audio out + Out
13 Right audio out + Out
14...17 Digital ground (to be used with the
signaling outputs)
18...20 Analogue ground (to be used with the
audio in and outputs)
21 Microphone - In
22 Left audio in - In
23 Right audio in - In
24 Left audio out - Out
25 Right audio out - Out
Table 4: DB25 connections
USB port; USB-B female
Pin Function Description
1 VCC + Supply
2 Data – Data
3 Data + Data
4 GND Ground
Table 5: USB connections
Network port; RJ45 female
Pin Function Description
1 TX-D + Data
2 TX-D – Data
3 RX-D + Data
4 Not in use
5 Not in use
6 RX-D – Data
7 Not in use
8 Not in use
Table 6: Network connections
