8

Installation

SPL2(TS) and SPL3(TS) user manual

EN

OVERLOAD Connection for LED's or solid-state-relays, for external signalling of the

OVERLOAD situation (20 V / 10 mA).

WARNING Connection for LED's or solid-state-relays, for external signalling of the

WARNING situation (20 V / 10 mA).

LIVE MODE OK Output for driving the switched power for the "live"-amplifiers (normally this

output is “on” (+20 V / 10 mA DC), in the case of sanction, current is

switched off.

SANCTION ACTIVE In SPL2 mode it is possible to apply an additional sanction when the

threshold is exceeded by more than 14dB. If this function is required pins 6

and 7 must be shorted.

MAINS Mains connection cable. The SPL limiters operate at 220 .. 240 V AC. The

limiter has a built-in self recovering fuse which does not need to be

replaced.
