11
SYNC I/O
7. REF IN/OUT
The SE-2600MU can be synchronized with
other studio equipment such as cameras.
REF IN accepts Tri-level or Black Burst sync.
REF OUT can be used to pass the sync signal
to other studio equipment such as cameras
or recorders.
Audio
8. AUDIO IN
Supports two XLR balanced audio input
channels.
Control
9. Ethernet Port
The DVIP port is designed for the user to
access the switcher’s settings and functions
on a PC/laptop or an Ethernet controller
from a remote location. You can either use a
static IP address to connect or connect with
DHCP. For details about using this port, refer
to the Ethernet control protocol document
which is available on the product page.
Please note that the switcher uses a static IP
address by default which is 192.168.100.101.
You can use the reset hole next to the USB
FW Upgrade port to restore the default IP
address. Use a needle to push the reset hole
then hold for about 5 to 10 seconds until the
machine reboots itself to restore the
switcher’s default IP address.
You can use any standard Ethernet cables to
connect. However, for transmission
distances over 100 meters, please use a
CAT6A 23 AWG Ethernet cable or higher.
Refer to Chapter 4 for Network Setup.
