Je bekijkt pagina 11 van 24
10
PA-530DAB
Ordercode: D6156
Mic 1 function DIP switches
Moving the DIP switches to ON/OFF, allows you to set up combo input 1. The available options are:
• Low-cut (Speech/Filter)
• Phantom
• Line/Mic
Low-cut (Speech/Filter): If set to ON, the device will cut off the lower frequencies of the input signal,
which will improve speech audibility. If set to OFF, the low frequencies will not be cut off.
Phantom power: If set to ON, the device will provide power to condenser microphones.
Line/Mic: If set to ON, the input sensitivity will be set for line inputs. If set to OFF, the input sensitivity will
be set for microphone level.
Gain level control – Mic 1
Adjust input level for Mic 1.
Combo input – Mic 1
Combo input for Mic 1. Accepts balanced or unbalanced inputs.
Aux – RCA IN
Connect an auxiliary signal source. The source selector (06) must be set to 3.
100V/8Ω terminal connector
If you connect a 100V speaker, connect the main feed cable (+) to the 100V terminal and the
common cable (-) to the 0 terminal.
If you connect a low impedance speaker, then connect the main feed cable (+) to the 8Ω terminal
and the common cable (-) to the 0 terminal.
NOTE: Do not connect the 100V and 8Ω speakers at the same time.
24V DC IN terminal connector
This input can be used in mobile applications, such as boats where 115 or 230V AC is not available or
in applications that must continue to operate in case of power shortage. When a 24V DC battery is
connected, the unit will operate on the supplied DC voltage. The amplifier has a built-in charger,
which charges the connected battery (lead acid battery only). Make sure, the amplifier is
connected to 115 V AC or 230 V AC to enable charging.
75 Ω FM antenna connector
Connect your FM/DAB+ antenna to this connector.
