9
PA-530DAB
Ordercode: D6156
Backside
Fig. 02
Air inlet
Do not obstruct the air inlet.
IEC power connector 115–230 V AC 50/60 Hz + fuse T1AL/250V
Connect the device to the appropriate power supply.
AC selector
Before connecting your PA-530DAB to the mains, make sure that the AC selector is set to the proper
voltage which is used in your country. In case of doubt, consult a technician.
Mic 2 function DIP switches
Moving the DIP switches to ON/OFF, allows you to set up combo input 2. The available options are:
• Low-cut (Speech/Filter)
• Phantom
• Line/Mic
Low-cut (Speech/Filter): If set to ON, the device will cut off the lower frequencies of the input signal,
which will improve speech audibility. If set to OFF, the low frequencies will not be cut off.
Phantom power: If set to ON, the device will provide power to condenser microphones.
Line/Mic: If set to ON, the input sensitivity will be set for line inputs. If set to OFF, the input sensitivity will
be set for microphone level.
Gain level control – Mic 2
Adjust input level for Mic 2.
Combo input – Mic 2
Combo input for Mic 2. Accepts balanced or unbalanced inputs.
