INSTALLATION & SERVICE MANUAL FOR PROFESSIONALS
Appendix: Technical data
en
Appendix
Technical data
Specication Abbr. Unit
HCV 400
P1
HCV 400
P2
HCV 400
E1
Operating range (min. @ 50Pa - max.
@ 100Pa)
V m/h 80 to 250 50 to 240 50 to 240
EN 13141-7 reference ow (@ 50Pa) V
REF
m/h 175 168 168
Performance
Temperature eciency in accordance
with EN13141-7
h
SUP
%
from 91%
to 97%
from 89%
to 96%
from 79%
to 94%
Specic power consumption in accor-
dance with EN13141-7 (@ ref. ow)
SEL/SPI
W/(m
3
/h)
0.23 0.19 0.20
Leakage (external and internal) in
accordance with EN13141-7
- % < 2 (Class A1)
Filters in accordance with ISO16890 /
EN779
- -
ISO Coarse 75% / G4
(optional: ePM1 55% / F7)
Ambient temperature for installation t
SURR
°C from +12 to +50
Outdoor temperature range without
installed preheater
t
ODA
°C from -12 to +50
Outdoor temperature range with
installed preheater
t
ODA
°C from -25 to +50
Maximum absolute humidity in
extract air
x g/kg 10
Cabinet:
Exterior dimensions (without wall
bracket)
W x H x D mm 540 x 1051 x 549
Spigots/duct connections Ø mm 160 - female
Weight m kg 39
Thermal conductivity -
polystyrene insulation
l
W/(mK) 0.031
Heat transfer coecient -
polystyrene insulation
U
W/
(m
2
K)
< 1
Fire class - polystyrene insulation -
-
DIN 4102-1 Class B2
EN 13501 Class E
Drainage hose Ø/length " / m 3/4” – 1m
Cabinet colour RAL - 9016
Electrical
Voltage U V 230
Max. power consumption (without/
with preheater)
P W 170/1,570
Frequency f
Hz
50
IP class class - 21
* The use of the preheating coil is recommended at outdoor temperatures below -3°C to
ensure balanced operation
Data sheet
HCV 400
