Table 9: Parameter List

[4] 38400 Baud

8-33 FC Port Parity

*[0] Even Parity, 1 Stop Bit

[1] Odd Parity, 1 Stop Bit

[2] No Parity, 1 Stop Bit

[3] No Parity, 2 Stop Bits

8-35 Minimum Response De-

lay

0.001–0.5 *0.010 s

8-36 Max Response Delay

0.100–10.00 s *5.000 s

8-4* FC MC protocol set

8-43 FC Port PCD Read Con-

guration

*[0] None Expressionlimit

[1] [1500] Operation Hours

[2] [1501] Running Hours

[3] [1502] kWh Counter

[4] [1600] Control Word

[5] [1601] Reference [Unit]

[6] [1602] Reference %

[7] [1603] Status Word

[8] [1605] Main Actual Value

[%]

[9] [1609] Custom Readout

[10] [1610] Power [kW]

[11] [1611] Power [hp]

[12] [1612] Motor Voltage

[13] [1613] Frequency

[14] [1614] Motor Current

[15] [1615] Frequency [%]

[16] [1618] Motor Thermal

[17] [1630] DC Link Voltage

[18] [1634] Heatsink Temp.

[19] [1635] Inverter Thermal

[20] [1638] SL Controller State

[21] [1650] External Reference

[22] [1651] Pulse Reference

[23] [1652] Feedback [Unit]

[24] [1660] Digital Input

18,19,27,33

[25] [1661] Digtial Input 29

[26] [1662] Analog Input 53

(V)

[27] [1663] Analog Input 53

(mA)

[28] [1664] Analog Input 60

[29] [1665] Analog Output 42

[mA]

[30] [1668] Freq. Input 33 [Hz]

[31] [1671] Relay Output [bin]

[32] [1672] Counter A

[33] [1673] Counter B

[34] [1690] Alarm Word

[35] [1692] Warning Word

[36] [1694] Ext. Status Word

8-5* Digital/Bus

8-50 Coasting Select

[0] DigitalInput

[1] Bus

[2] LogicAnd

*[3] LogicOr

8-51 Quick Stop Select

See par. 8-50 * [3] LogicOr

8-52 DC Brake Select

See par. 8-50 *[3] LogicOr

8-53 Start Select

See par. 8-50 *[3] LogicOr

8-54 Reversing Select

See par. 8-50 *[3] LogicOr

8-55 Set-up Select

See par. 8-50 *[3] LogicOr

8-56 Preset Reference Select

See parameter 8-50 * [3] Logi-

cOr

8-8* Bus communication Di-

agnostics

8-80 Bus Message Count

0-0 N/A *0 N/A

8-81 Bus Error Count

0-0 N/A *0 N/A

8-82 Slave Messages Rcvd

0-0 N/A *0 N/A

8-83 Slave Error Count

0-0 N/A *0 N/A

8-9* Bus Jog / Feedback

8-94 Bus feedback

1 0x8000-0x7FFF *0

13-** Smart Logic

13-0* SLC Settings

13-00 SL Controller Mode

*[0] O

[1] On

13-01 Start Event

[0] False

[1] True

[2] Running

[3] InRange

[4] OnReference

[7] OutOfCurrentRange

[8] BelowILow

[9] AboveIHigh

[16] ThermalWarning

[17] MainOutOfRange

[18] Reversing

[19] Warning

[20] Alarm_Trip

[21] Alarm_TripLock

[22-25] Comparator 0-3

[26-29] LogicRule0-3

[33] DigitalInput_18

[34] DigitalInput_19

[35] DigitalInput_27

[36] DigitalInput_29

[38] DigitalInput_33

*[39] StartCommand

[40] DriveStopped

13-02 Stop Event

See parameter 13-01

* [40] DriveStopped

13-03 Reset SLC

*[0] Do not reset

[1] Reset SLC

13-1* Comparators

13-10 Comparator Operand

*[0] Disabled

[1] Reference

[2] Feedback

[3] MotorSpeed

[4] MotorCurrent

[6] MotorPower

[7] MotorVoltage

[8] DCLinkVoltage

[12] AnalogInput53

[13] AnalogInput60

[18] PulseInput33

[20] AlarmNumber

[30] CounterA

[31] CounterB

13-11 Comparator Operator

[0] Less Than

*[1] Approximately equals

[2] Greater Than

13-12 Comparator Value

-9999–9999 *0.0

13-2* Timers

13-20 SL Controller Timer

0.0–3600 s *0.0 s

13-4* Logic Rules

13-40 Logic Rule Boolean 1

See par. 13-01 *[0] False

[30] - [32] SL Time-out 0-2

13-41 Logic Rule Operator 1

*[0] Disabled

[1] And

[2] Or

[3] And not

[4] Or not

[5] Not and

[6] Not or

[7] Not and not

[8] Not or not

13-42 Logic Rule Boolean 2

See par. 13-40 * [0] False

13-43 Logic Rule Operator 2

See par. 13-41 *[0] Disabled

13-44 Logic Rule Boolean 3

See par. 13-40 * [0] False

13-5* States

13-51 SL Controller Event

See par. 13-40 *[0] False

13-52 SL Controller Action

*[0] Disabled

[1] NoAction

[2] SelectSetup1

[3] SelectSetup2

[10-17] SelectPresetRef0-7

[18] SelectRamp1

[19] SelectRamp2

[22] Run

[23] RunReverse

[24] Stop

[25] Qstop

[26] DCstop

[27] Coast

[28] FreezeOutput [29] Start-

Timer0

[30] StartTimer1

[31] StartTimer2

[32] Set Digital Output A Low

[33] Set Digital Output B Low

[38] Set Digital Output A High

[39] Set Digital Output B High

[60] ResetCounterA

[61] ResetCounterB

14-** Special Functions

14-0* Inverter Switching

14-01 Switching Frequency

[0] 2 kHz

*[1] 4 kHz

[2] 8 kHz

[4] 16 kHz not available for M5

14-03 Overmodulation

[0] O

Parameter Overview

VLT® Micro Drive FC 51

Operating Guide
