Table 8: Parameter List

[3] Drive ready, Remote

[4] Enable / No warning

[5] Drive running

[6] Running / No warning

[7] Run in range / No warning

[8] Run on ref / No warning

[9] Alarm

[10] Alarm or warning

[12] Out of current range

[13] Below current, low

[14] Above current, high

[16] Below frequency, low

[17] Above frequency, high

[19] Below feedback, low

[20] Above feedback, high

[21] Thermal warning

[22] Ready, No thermal warn-

ing

[23] Remote ready, No ther-

mal warning

[24] Ready, Voltage ok

[25] Reverse

[26] Bus ok

[28] Brake, NoWarn

[29] Brake ready/NoFault

[30] BrakeFault (IGBT)

[32] Mech.brake control

[36] Control word bit 11

[41] Below reference, low

[42] Above reference, high

[51] Local ref. active

[52] Remote ref. active

[53] No alarm

[54] Start cmd active

[55] Running reverse

[56] Drive in hand mode

[57] Drive in auto mode

[60-63] Comparator 0-3

[70-73] Logic rule 0-3

[81] SL digital output B

5-41 On Delay, Relay

0.00–600.00 s *0.01 s

5-42 O Delay, Relay

0.00–600.00 s *0.01 s

5-5* Pulse Input

5-55 Terminal 33 Low Fre-

quency

20–4999 Hz *20 Hz

5-56 Terminal 33 High Fre-

quency

21–5000 Hz *5000 Hz

5-57 Term. 33 Low Ref./Feedb.

Value

-4999–4999 *0.000

5-58 Term. 33 High Ref./

Feedb. Value

-4999–4999 *50.000

6-** Analog In/Out

6-0* Analog I/O Mode

6-00 Live Zero Timeout Time

1-99 s *10 s

6-01 Live Zero TimeoutFunc-

tion

*[0] O

[1] Freeze output

[2] Stop

[3] Jogging

[4] Max speed

[5] Stop and trip

6-1* Analog Input 1

6-10 Terminal 53 Low Voltage

0.00–9.99 V *0.07 V

6-11 Terminal 53 High Voltage

0.01–10.00 V *10.00 V

6-12 Terminal 53 Low Current

0.00–19.99 mA *0.14 mA

6-13 Terminal 53 High Current

0.01–20.00 mA *20.00 mA

6-14 Term. 53 Low Ref./Feedb.

Value

-4999-4999 *0.000

6-15 Term. 53 High Ref./

Feedb. Value

-4999-4999 *50.000

6-16 Terminal 53 Filter Time

Constant

0.01–10.00 s *0.01 s

6-19 Terminal 53 mode

*[0] Voltage mode

[1] Current mode 4

6-2* Analog Input 2

6-22 Terminal 60 Low Current

0.00–19.99 mA *0.14 mA

6-23 Terminal 60 High Current

0.01–20.00 mA *20.00 mA

6-24 Term. 60 Low Ref./Feedb.

Value

-4999-4999 *0.000

6-25 Term. 60 High Ref./

Feedb. Value

-4999–4999 *50.00

6-26 Terminal 60 Filter Time

Constant

0.01–10.00 s *0.01 s

6-8* LCP Potentiometer

6-80 LCP Potmeter Enable

[0] Disabled

*[1] Enable

6-81 LCP potm. Low Refer-

ence

-4999–4999 *0.000

6-82 LCP potm. High Refer-

ence

-4999–4999 *50.00

6-9* Analog Output xx

6-90 Terminal 42 Mode

*[0] 0-20 mA

[1] 4-20 mA

[2] Digital Output

6-91 Terminal 42 Analog Out-

put

*[0] No operation

[10] Output Frequency

[11] Reference

[12] Feedback

[13] Motor Current

[16] Power

[19] DC Link Voltage

[20] Bus Reference

6-92 Terminal 42 Digital Out-

put

See parameter 5-40

*[0] No Operation

[80] SL Digital Output A

6-93 Terminal 42 Output Min

Scale

0.00-200.0% *0.00%

6-94 Terminal 42 Output Max

Scale

0.00-200.0% *100.0%

7-** Controllers

7-2* Process Ctrl. Feedb

7-20 Process CL Feedback 1

Resource

*[0] NoFunction

[1] Analog Input 53

[2] Analog input 60

[8] PulseInput33

[11] LocalBusRef

7-3* Process PI Ctrl.

7-30 Process PI Normal/ In-

verse Ctrl

*[0] Normal

[1] Inverse

7-31 Process PI Anti Windup

[0] Disable

*[1] Enable

7-32 Process PI Start Speed

0.0–200.0 Hz *0.0 Hz

7-33 Process PI Proportional

Gain

0.00–10.00 *0.01

7-34 Process PI Integral Time

0.10–9999 s *9999 s

7-38 Process PI Feed Forward

Factor

0–400% *0%

7-39 On Reference Bandwidth

0–200% *5%

8-** omm. and Options

8-0* General Settings

8-01 Control Site

*[0] Digital and ControlWord

[1] Digital only

[2] ControlWord only

8-02 Control Word Source

[0] None

*[1] FC RS485

8-03 Control Word Timeout

Time

0.1–6500 s *1.0 s

8-04 Control Word Timeout

Function

*[0] O

[1] Freeze Output

[2] Stop

[3] Jogging

[4] Max. Speed

[5] Stop and trip

8-06 Reset Control Word

Timeout

*[0] No Function

[1] Do reset

8-3* FC Port Settings

8-30 Protocol

*[0] FC

[2] Modbus

8-31 Address

1-247 *1

8-32 FC Port Baud Rate

[0] 2400 Baud

[1] 4800 Baud

*[2] 9600 Baud For choose FC

Bus in 8-30

*[3] 19200 Baud For choose

Modbus in 8-30

Parameter Overview

VLT® Micro Drive FC 51

Operating Guide
