Steering unit Displacement
manual steer
mode
cm³/rev
[in³/rev]
Displacement
normal steer
mode
cm³/rev
[in³/rev]
Rated oil
flow
*
l/min
[US gal/min]
Max. pressure, bar (psi)
System
Pressure
P-T port
pressure
T,
absolute
port
pressure
L-T/R-T
port
pressure
OSPD 60/185 LSR 60 [3.66] 185 [11.29] 19 [5.02] 210 [3045] 40 [580] 280 [4061]
OSPD 60/220 LSR 60 [3.66] 220 [13.42] 22 [5.81]
OSPD 70/195 LSR 70 [4.27] 195 [11.90] 20 [5.28]
OSPD 100/200 LSR 100 [6.10] 200 [12.20] 20 [5.28]
*
Rated flow at 100 rpm.
Displacement, flow and pressure: OSPL LS, OSPBX LS, OSPCX LS, OSPLX LS
Steering unit Displacement
cm³/rev
[in³/rev]
Rated oil
flow
*
l/min
[US gal/min]
Max. pressure, bar (psi)
System
pressure
P-T port
pressure
T,
absolute
port
pressure
L-R
port
pressure
OSPL 520 LS Static 520 [31.73] 52 [13.74] 240 [3480] 40 [580] 280 [4061]
OSPL 630 LS Static 630 [38.44] 63 [16.64]
OSPL 800 LS Static 800 [48.82] 80 [21.10]
OSPL 1000 LS Static 1000 [61.02] 100 [26.40]
OSPL 520 LS Dynamic 520 [31.73] 52 [13.74] 240 [3080] 40 [580] 280 [4061]
OSPL 630 LS Dynamic 630 [38.44] 63 [16.64]
OSPL 800 LS Dynamic 800 [48.82] 80 [21.10]
OSPL 1000 LS Dynamic 1000 [61.02] 100 [26.40]
OSPL 1200
**
Dynamic 1200 [73.22] 100 [26.40]
OSPBX 160 LS Static 160 [9.76] 16 [4.23] 210 [3045] 40 [580] 280 [4061]
OSPBX 200 LS Static 200 [12.20] 20 [5.28]
OSPBX 250 LS Static 250 [15.25] 25 [6.60]
OSPBX 315 LS Static 315 [19.22] 32 [8.45]
OSPBX 400 LS Static 400 [24.41] 40 [10.57]
OSPCX 160 LS Dynamic 160 [9.76] 16 [4.23] 210 [3045] 40 [580] 280 [4061]
OSPCX 200 LS Dynamic 200 [12.20] 20 [5.28]
OSPCX 250 LS Dynamic 250 [15.25] 25 [6.60]
OSPCX 315 LS Dynamic 315 [19.22] 32 [8.45]
OSPCX 400 LS Dynamic 400 [24.41] 40 [10.57]
OSPLX 520 LS Static 520 [31.73] 52 [13.74] 240 [3480] 40 [580] 280 [4061]
OSPLX 630 LS Static 630 [38.44] 63 [16.64]
OSPLX 800 LS Static 800 [48.82] 80 [21.10]
*
Rated flow at 100 rpm.
**
OSPL 1200 max speed at 100l/min [26.4 US gal/min] 83 rpm.
Technical Information
OSPB/C/F/D/L LS Steering Units, OLS Priority Valves, OSQ Flow Amplifiers
LS Steering Units OSPB, OSPC, OSPF, OSPD, OSPL
©
Danfoss | April 2021 BC152886483962en-001003 | 25
