13
INSTALLATION INSTRUCTIONS
INSTALLATION IN A SLIDING WINDOW
8. Attach the side channels.
Fasten the side channels to the sides of the air
conditioner using the provided screws. Make sure
the hook ends of the channels face the rear of the
appliance.
9. Assemble the window panel and frame
Slide the plastic window panel into the panel frame
with the smooth side facing the room. Slide the
panel frame assembly into the side channels of
the air conditioner cabinet. Make sure the plastic
window panel is firmly enclosed on all sides by the
retainer grooves.
10. Add the weather stripping.
Cut the side channel foam seal into two equal
lengths. Remove the protective backing and apply it
to the rear side of the cabinet side channels, starting
just below the panel frame assembly. Cut of any
excess length so the seal is even with the bottom of
the cabinet side channel.
11. Remove the front panel.
Remove the two front retaining screws from the front
frame. Pull the front out and lift up to release the
front cover from the cabinet. Release the coupler
plugs. Removing the front panel will allow you to
install the safety bracket in step 13.
