12
INSTALLATION INSTRUCTIONS
INSTALLATION IN A SLIDING WINDOW
5. Add a siding protection board.
A siding protection board can be used to protect the
house siding from damage. The board should be
long enough to span two wall studs.
Adjust the platform assembly so that the air
conditioner will be 1” to 1 1/4” lower in the back,
tilted approximately 3° to 4° downward to the
outside. This allows condensation that forms inside
the appliance during normal use to drain to the
outside.
6. Install the platform assembly.
Place the platform assembly in the window with the
platform tab against the inside of the window track
and attach it to the window jamb using the provided
screws.
Ensure that the platform assembly is tilted 1” to 1
1/4” (3° to 4°) downward to the outside.
Ensure that the platform assembly is level from side
to side. Make sure the window track is level. Use
leveling shims as necessary to ensure the appliance
is level.
7. Cut the plastic window panel.
Measure the height of the window opening from
the top of the platform assembly to the top of the
window opening. Subtract 20 5/8” to account
for the size of the air conditioner and mark the
measurement on the plastic window panel along the
longer side. Cut the panel to the correct size and
remove any burrs with a file.
1” - 1.25”
