9
INSTALLATION INSTRUCTIONS
IMPORTANT
Disconnect power before servicing. Improper connection of aluminum house wiring and copper
appliance leads can result in an electrical hazard or fire. If the home has aluminum wiring, only
use connections designed and UL listed for joining copper to aluminum and precisely follow the
manufacturer’s recommend procedure. Aluminum-to-Copper connections must conform with local
codes. Use 8-gauge copper or 6-gauge aluminum wire. Electrically ground range.
CONNECTION TO HOUSE ELECTRICAL SUPPLY
Be sure your appliance is properly installed and grounded by a qualified technician.
• A circuit breaker is recommended.
• The range can be connected directly to the circuit breaker box (or fused disconnect) through flexible or
nonmetallic sheathed, copper or aluminum cable.
• Allow at least 6 ft (1.8M) of slack in the line so that the range can be moved if servicing is every
necessary.
• A UL listed conduit connector must be provided at each end of the power supply cable (at the range
and at the junction box).
The wiring diagram is included with the range. This appliance is manufactured with the chassis connected
to a neutral by a green ground jumper wire. After making sure that the power has been turned off, connect
the flexible conduit from the range to the junction box using a UL listed conduit connector. The Grounded
Neutral and Ungrounded Neutral Graphics on the following pages and the instruction provided, present
the most common way of connecting the range. Your local codes and ordinances take precedence over
these instruction. Complete electrical connections according to local codes and ordinances.
PARTS NEEDED:
If using a power supply cord:
• UL listed power supply cord kit marked for use with ranges. The cord should be rated at 250V
minimum, 40 amps or 50 amps that is marked for use with nominal 1 3/8” (3.5 cm) diameter
connection opening and must end in ring terminals or open-end spade terminals with upturned ends.
• UL listed strain relief.
If direct wiring:
• Flexible Metal Conduit
• UL Listed Conduit Connector
• 4-wire or 3-wire Electrical Cable (where local codes permit a 3-wire connection)
• UL Listed Wire Connectors
NOTES:
• Check local codes.
• Check existing electrical supply.
