INSTALLATION INSTRUCTIONS

NOTE: The safety distance between the hotplate and the cupboard above the hotplate should be at least

30” (760mm).

A B C D E

29 29/32”

760mm

1 15/16”

50mm minimal

13/16”

20mm minimal

Air intake 3/16”

Air exit 5mm

Before inserting the hob into the opening of the kitchen worktop, the supplied foam gasket (located

in a plastic bag) must be attached to the lower side of the ceramic glass

IMPORTANT: Do not install the hob without the foam gasket!

INSTALLING THE FOAM GASKET

1. Remove the protective film from the gasket

2. Attach the gasket to the lower side of the glass, next to the edge

3. The gasket must be attached along the entire length of the glass edge, and should not overlap at the

corners

NOTE: When installing the gasket please ensure the glass does not come into contact with any sharp

objects

Foam

Gasket
