8
in larger areas where high quali sound is desired. DALI recommends the use of a
subwoofer together with DALI PHANTOM M-80A to permit reproduction of the
lowest frequencies and an overall enhancement of your sound system.
For stereo and home cinema we recommend that you position the loud speakers
symmetrically around your favourite listening position to achieve optimum soundstage
(see figure 1A + 1B + 1C). To avoid compromising clari from the loudspeaker, it is also
important, that you do not position the loudspeaker too far away from the listening
position. We recommend that the greatest o axis listening angle is 45 degrees
(measured between the centre axis of the loudspeaker and the listening position –
see figure 2).
In a distributed sound system setup it is important, that the loudspeakers are
positioned so that the main area of the room(s) is covered with sound (see chapter
4.4). To achieve an even sound coverage, the loudspeakers should be installed evenly
in the room(s) (see figure 3).
The PHANTOM M-80 A (angled) in-ceiling Hi-Fi speaker incorporates a 7 inch
bass/midrange driver, angled at 25°, to provide sound radiation that is preferentially
beamed in one direction. Preferential beaming enables M-80A speaker placement
that ensures optimum dispersion for the specific audio installation to maximise sound
quali at the listening position. The M-80A additionally incorporates compass sle
direction indicators further to configure dispersion to suit the installation.
Place the speaker in the desired spot and use the compass positioning guide to beam
the sound into the main listening position.
Every room has its own distinctive acoustics, which influence the way we experience
sound from a loudspeaker. The sound you hear consists of both direct sound from
the loudspeakers and reflected sound from the floor, ceiling and walls. The laer will
aect how you experience the sound. As a basic rule, try to avoid large, hard and
reflective areas in the immediate vicini of your loudspeakers as it will pically cause
strong reflections, which might disturb the precision and spatial eect of the sound
reproduction. So items such as carpets, curtains etc. might help if the sound is too
bright.
Both the amount and quali of the deep bass depend on the size and shape of the
room, and the position of the loudspeakers. Positioning the loudspeakers near a side
or back wall will accentuate the bass. A corner location will accentuate it even more,
but will also increase the reflections.
4.1 Mounting the dogleg brackets
DALI PHANTOM M-80 A incorporates dogleg brackets for ceiling mounting. The
brackets aach the loudspeaker firmly to the rear of the surface on which it is
mounted. The dogleg brackets extend out at a 90-degree angle when the screws
are tightened (see figure 4). The screws should be tightened so that the loudspeaker
sits securely in place – but be careful not to over tighten the screws. To tighten the
screws, use an appropriate bit. The bit should be used with a hand bit screwdriver or
a drilling machine with build-in torque seing. If using a drilling machine, set the torque
