10
When connecting the cable to the loudspeaker and the amplifier, it is important that
the loudspeaker is connected in correct polari. The red (+) loudspeaker terminal
must be connected to the red (+) amplifier terminal. The black (-) loudspeaker
terminal must be connected to the black (-) amplifier terminal. If the loudspeakers
are not connected in correct polari, the soundstage will pically be diuse and the
bass will be weak.
To insert the cable end into the spring loaded terminals of the loudspeaker, remove
cable insulation so that approximately ½” / 12mm of bare wire is exposed. Press the
top of the terminal down and insert the bare wire into the opening. When the wire is
fully in place with no loose strands exposed, release the terminal. The cable is now
connected. Please refer to figure 8 for correct cable connection.
5.0 CUT-OUT TEMPLATE
The enclosed cut-out template (see figure 9) can be used to initially visualize how your
loudspeakers should be mounted and for marking where the cut-out should be made.
Tape the template at the preferred mounting position, so that you can mark the
necessary opening. The minimum mounting depth for the DALI PHANTOM M-80A
can be found in the Technical Specifications.
6.0 INSTALLATION
Please study and follow the safe guidelines found in chapter 2.0 of this manual! Use
a trained professional to ensure that all safe requirements are met to prevent the
loudspeaker from falling.
The following tools and items are necessary for proper installation:
• Tape measure
• Pencil and saw or knife
• Appropriate bit or screwdriver
• Tape
• Cut-out template
When the correct placement has been found, tape the mounting template to the
surface. Outline the cut-out area with a pencil.
Remove the template and drill holes for insertion of saw or knife. Saw/cut carefully
along the line marked with pencil.
When the hole for the loudspeaker is made, make sure that the loudspeaker cable
is not hanging loose inside the ceiling/wall. It must be securely fastened to the inside
of the ceiling/wall to prevent tension on the cable when the cable is connected with
the terminals of the loudspeaker. If le unsupported, cable can gradually come loose,
creating a poor electrical connection between wire and terminals (see figure 8 for
correct fastening of the cable).
When the speaker cable is fastened and the hole for the loudspeaker is prepared,
you are ready to connect the speaker cables. Connect cable to the terminals –
