Air Conditioner Service Manual
44
Refigerant leakage detection
The piping joint,the connector of the two valves of the outdoor
unit,the valve spool,the welding port,etc.where leakage may occur.
Foam detection method:
Apply soapy water or foam evenly on the parts where leakage may
occur, and observe whether bubbles appear or not,if not,it indicates that
the leakage detection result if safe.
Leak detector method:
Use a professional leak detector and read the instruction of
operation, detect at the position where leakage may occur.
The duration of leak detection for each position should last for 3
minutes
or more;
If the test result shows that there ie leakage,the nut should be tightened
and tested again until there ie no leakage;
After the leak detection is completed,wrap the exposed pipe connector
of indoor unit with thermal insulation material and wrap with insulation
tape.
Test Running Instruction
1. Turn on the power supply.
2. Press the ON/OFF button on the remote controller to turn on the air conditioner .
3. Press the Mode button to switch the mode COOLING and HEATING.
In each mode set as below:
COOLING-Set the lowest temperature
HEATING-Set the highest temperature
4. Run about 8 minutes in each mode and check all functions are properly run and respond the remote
controller. Functions check as recommended:
4.1 If the outlet air temperature responds to the cooling and heating modes
4.2 If the water drains properly from the drainage hose
4.3 If the Louver and deflectors(optional) rotae properly
5. Observe the test run state of the air conditioner at least 30 minutes.
6. After the successfully test run, return the normal setting and press ON/OFF button on the remote controller
to turn off the unit.
7. Inform the user to read this manual carefully before use, and demonstrate to the user how to use the air
conditioner, the necessary knowledge for service and maintenance, and the reminder for storage of
