9 | Charging refrigerant
Installer reference guide
60
RZASG100~140MUV/Y
Sky Air Advance-series
4P743506-1 – 2023.08
9.5 Charging additional refrigerant
9.5.1 To determine the additional refrigerant amount
To determine if adding additional refrigerant is necessary
If Then
(L1+L2+L3+L4+L5+L6+L7)≤ 30m
(chargeless length)
You do not have to add additional
refrigerant.
(L1+L2+L3+L4+L5+L6+L7)> 30m
(chargeless length)
You must add additional refrigerant.
For future servicing, encircle the
selected amount in the tables below.
INFORMATION
Piping length is the largest one-way length of liquid piping.
To determine the additional refrigerant amount (R in kg) (in case of pair)
L1 (m)
L1: 30~40m 40~50m
R: 0.35kg 0.7kg
To determine the additional refrigerant amount (R in kg) (in case of twin, triple
and double twin)
1 Determine R1 and R2.
If Then
G1>30m Use the table below to determine R1
G1≤30m
(and G1+G2>30m)
R1=0.0kg.
Use the table below to determine R2
Length (total length of liquid piping−30m)
0~10m 10~20m 20~30m 30~40m 40~45m
R1: 0.35kg 0.7kg 1.05kg 1.4kg
R2: 0.2kg 0.4kg 0.6kg 0.8kg 1kg
(a)
(a)
Only for RZASG100+125.
2 Determine the additional refrigerant amount: R=R1+R2.
