8 | Electrical installation
Installer reference guide
53
RZASG100~140MUV/Y
Sky Air Advance-series
4P743506-1 – 2023.08
1 Remove the service cover. See "6.2.2To open the outdoor unit"[427].
2 Strip insulation (20mm) from the wires.
a b
a Strip wire end to this point
b An excessive strip length may cause electrical shock or leakage
3 Connect the interconnection cables and power supply as follows:
c
a
d
e
1~ 50 Hz
220-240 V
3N~ 50 Hz
380-415 V
RZASG-MV RZASG-MY
L1 L2 L3
L1 L2 L3
N
b
b
a
a
a
I, II, III, IV Pair, twin, triple, double twin
M, S Master, slave
a Interconnection cables
b Power supply cable
c Earth leakage circuit breaker
d Fuse
e User interface
Example: RZASG100~140MUV
c
ef
b g
d
d
a
a Switch box
b Stop valve attachment plate
c Terminal block
d Earth wire
e Power supply cable
f Interconnection cable
