8 | Electrical installation
Installer reference guide
52
RZASG100~140MUV/Y
Sky Air Advance-series
4P743506-1 – 2023.08
8.1.3 About electrical compliance
RZASG100~140MUV
Equipment complying with EN/IEC 61000‑3‑12 (European/International Technical
Standard setting the limits for harmonic currents produced by equipment
connected to public low-voltage systems with input current >16A and ≤75A per
phase.).
RZASG100~140MUY
Equipment complying with EN/IEC 61000‑3‑2 (European/International Technical
Standard setting the limits for harmonic currents produced by equipment
connected to public low-voltage systems with input current ≤16A per phase.).
8.2 Connections to the outdoor unit
8.2.1 Specifications of standard wiring components
Component RZASG100~140MUV RZASG100~140MUY
100 125 140 100 125 140
Power supply cable MCA
(a)
22.7A 29.2A 28.5A 14.9A 15.7A 15.4A
Voltage range 220~240V 380~415V
Phase 1~ 3N~
Frequency 50Hz
Wire sizes Must comply with national wiring regulation
3-core cable 5-core cable
Wire size based on the current, but not less than:
Minimum 4.0mm
2
Minimum 2.5mm
2
Interconnection cable
(indoor ↔ outdoor)
Voltage 220-240V
Wire size Only use harmonised wire providing double insulation and
suitable for applicable voltage.
4-core cable
Minimum 2.5mm
2
Recommended field fuse 25A 32A 16A
Earth leakage circuit breaker / residual current
device
Must comply with national wiring regulation
(a)
MCA=Minimum circuit ampacity. Stated values are maximum values (see electrical data of combination with indoor units for exact
values).
8.2.2 To connect the electrical wiring to the outdoor unit
NOTICE
▪ Follow the wiring diagram (delivered with the unit, located at the inside of the
service cover).
▪ Make sure the electrical wiring does NOT obstruct proper reattachment of the
service cover.
