7 | Piping installation
Installer reference guide
36
RZASG100~140MUV/Y
Sky Air Advance-series
4P743506-1 – 2023.08
Piping Diameter
L2,L3 (double twin) Liquid piping: Ø9.5mm
Gas piping: Ø15.9mm
L1 (pair, twin, triple, double twin):
Model New
(a)
/
Existing
(b)
L1 liquid piping L1 gas piping
RZASG100~140 Standard Ø9.5mm Ø15.9mm
(a)
When installing new piping, use the same diameters as the connections on the outdoor
units (i.e. standard diameters for liquid and gas piping).
(b)
When reusing existing piping, you may use the size‑up or size‑down diameters, but then
capacity might decrease, and stricter piping length requirements are applicable. Assess
these limitations in relation to the complete installation.
7.1.5 Refrigerant piping length and height difference
The piping lengths and height differences must comply with the following requirements:
Requirement Limit
RZASG100 RZASG125 +
RZASG140
1 Minimum total one‑way piping
length
Pair: Limit≤L1
Twin: Limit≤L1+L3
Triple: Limit≤L1+L4
Double twin: Limit≤L1+L3+L7
5m
2 Maximum total one‑way piping
length
Pair: L1≤Limit 50m (70m)
(a)
Twin and triple: L1+L2≤Limit
Double twin: L1+L2+L4≤Limit
50m (70m)
(a)
3 Maximum allowable piping length Pair: N/A —
Twin: L1+L2+L3≤Limit 50m
Triple: L1+L2+L3+L4≤Limit 50m
Double twin:
L1+L2+L3+L4+L5+L6+L7≤Limit
— 50m
4 Maximum branch piping length Pair: N/A
Twin and triple: L2≤Limit
Double twin: L2+L4≤Limit
20m
5 Maximum difference between
branch lengths
Pair: N/A —
Twin: L2–L3≤Limit 10m
Triple: L2–L4≤Limit 10m
Double twin:
▪ L2–L3≤Limit
▪ L4–L5≤Limit
▪ L6–L7≤Limit
▪ (L2+L4)–(L3+L7)≤Limit
— 10m
