9 | Electrical installation
Installer reference guide
50
RXA-B8, RXM-A(9), ARXM-A(9), RXP-N9, RXF-D(9), ARXF-A(9), RZAG-B
R32 split series
4P766272-2 – 2024.01
1-3
9.1.3 Specifications of standard wiring components
Power supply of the product
Voltage 220~240V
Frequency 50Hz
Phase 1~
Current RXA: 12.9A
ARXM, RXM50+60: 15.92A
RXM71: 19.91A
RXP50, RXF50, ARXF50: 15.13A
RXP60+71, RXF60+71, ARXF60+71: 15.7A
RZAG35+50: 15.63A
RZAG60:17.4A
Wiring / circuit breaker (field supplied)
Power supply cable MUST comply with national wiring regulation
3-core cable
Wire size based on the current, but not less than
2.5mm
2
Interconnection cable
(indoor↔outdoor)
Only use harmonised wire providing double
insulation and suitable for applicable voltage
4-core cable
Minimum size 1.5mm
2
Recommended circuit breaker RXA: 13A
ARXM, RXM50+60, RXP, RXF, ARXF, RZAG35+50:
16A
RXM71, RZAG60: 20A
(a)
Earth leakage circuit breaker /
residual current circuit
breaker
MUST comply with national wiring regulation
(a)
Electrical equipment complying with EN/IEC 61000-3-12 (European/International Technical
Standard setting the limits for harmonic currents produced by equipment connected to
public low-voltage systems with input current >16A and ≤75A per phase).
9.2 To connect the electrical wiring to the outdoor unit
1 Remove the switch box cover.
