18 Configuration
Installation and operation manual
42
REMA5+REYA8~20A7Y1B
VRV 5 heat recovery
4P684060-1C – 2024.10
What How
Changing the value of the
selected setting in mode2
▪ Push BS1 for more than fiveseconds
to select mode2.
▪ Push BS2 to select the required
setting.
▪ Push BS3 one time to access the
selected setting's value.
▪ Push BS2 to select the required value
of the selected setting.
▪ Push BS3 one time to validate the
change.
▪ Push BS3 again to start operation
with the chosen value.
18.1.7 Mode 1: monitoring settings
[1-0]
Shows whether the unit you check is a master or slave unit.
The master unit should be used to input field settings in
mode2.
[1‑0] Description
No indication Undefined situation.
0 Outdoor unit is master unit.
1 Outdoor unit is slave1 unit.
[1‑1]
Shows the status of low noise operation.
[1‑1] Description
0 Unit is currently not operating under low noise
restrictions.
1 Unit is currently operating under low noise
restrictions.
[1‑2]
Shows the status of power consumption limitation operation.
[1‑2] Description
0 Unit is currently not operating under power
consumption limitations.
1 Unit is currently operating under power
consumption limitation.
[1‑5] [1‑6]
Code Shows ...
[1‑5] The current T
e
target parameter position
[1‑6] The current T
c
target parameter position
[1‑10]
Shows the total number of connected indoor units.
[1‑13]
Shows the total number of connected outdoor units (in case of
multiple outdoor system).
[1‑17] [1‑18] [1‑19]
Code Shows ...
[1‑17] The latest malfunction code
[1‑18] The 2nd last malfunction code
[1‑19] The 3rd last malfunction code
[1‑29] [1‑30] [1‑31]
Shows the result of the leak detection function.
Result Description
No data
Result Description
Leak detection failure due to abnormal
operation
No leak detected
Leak detected
[1‑34]
Shows the remaining days until the next automatic leak detection (if
automatic leak detection function is activated).
[1‑40] [1‑41]
Code Shows ...
[1‑40] The current cooling comfort setting
[1‑41] The current heating comfort setting
18.1.8 Mode 2: field settings
[2‑8]
T
e
target temperature during cooling operation.
[2‑8] T
e
target [°C]
0 (default) Auto
2 6
3 7
4 8
5 9
6 10
7 11
[2‑9]
T
c
target temperature during heating operation.
[2‑9] T
c
target [°C]
0 (default) Auto
1 41
2 42
3 43
4 44
5 45
6 46
[2‑14]
Input additional refrigerant amount that was charged.
In case you want to use the automatic leak detection functionality, it
is required to input the total additional refrigerant charge amount.
[2‑14] Additional amount charged [kg]
0 (default) No input
1 0<x<5
2 5<x<10
3 10<x<15
4 15<x<20
5 20<x<25
6 25<x<30
7 30<x<35
8 35<x<40
9 40<x<45
10 45<x<50
11 50<x<55
12 55<x<60
