3 About the unit and options
Operation manual
8
LMCEY1A/W + LMCEY2A/W
Daikin LMC
4P753996-1 – 2024.06
LMCEY2A/W
IN
ba
cd
a Flammable materials
b
Thermal hazard
c
Water inlet indication (LMCEY1W+LMCEY2W only)
d
Electrical hazard
3.5
Possible options for the unit
INFORMATION
Certain options may NOT be available in your country.
NOTICE
The use of accessories and/or options other than those
approved by Daikin may cause system malfunctions and
automatically void the warranty, relieving the manufacturer
from any damage caused to persons, animals and/or
property.
Four cable glands (f) are provided to bring the option cables into the
unit.
b fc da e
a
Cell light wire (2 m), C3 labelled
b
Remote control panel, pre-wired (5 m)
c
Door heater, pre-wired (5 m), C2 labelled
d
Door switch, pre-wired (5 m), C4 labelled
e
Power supply, pre-wired (5 m), C1 labelled
f
For optional use
Door switch (3MCT014ACC)
To reduce frost on the evaporator, the door switch interrupts the unit
operation when the cold room door is open. It also controls the cell
light. The door switch is an option.
If the door remains open for longer than the value of parameter Add,
control resumes in any case. The light remains on, the measurement
shown on the display flashes, the buzzer and the alarm relay (if
enabled) are activated, and the temperature alarms are enabled with
60 minutes of delay.
Door heater
For low temperature applications it is suggested to install a door
heater. It prevents the door from freezing. The choice for the most
appropriate door heater is left to the installer or cold room
manufacturer. Sometimes the door heater is already included in the
pre-fabricated door kit.
INFORMATION
The door heater is only necessary for low temperature
applications.
Cell light (1KIT862ACC)
The light is ON when the cold room door is open. The time during
which the light stays on after closing the door is set by the parameter
H14, and can be set from 0 to 240 minutes. See "4.3.3To change
the parameters"[412].
The cell light can also be controlled by the user interface or via the
Daikin apps.
The cell light is an option.
INFORMATION
There are 4 free cable glands available for options. Only 4
extra options can be installed.
Alarm
An alarm feature can be installed (light or sound).
Router
The unit (or multiple units) can be connected to the network through
a router, available as an option.
uBOSS Wi-Fi (wireless, 3MCB002ACC)
da cb
e f
OR
a LMC unit
b
RS485 cable
c
Access point (external router)
d
Devices
e
Gateway µBOSS
f
LAN cable
OR
Choice between WiFi or LAN cable
uBOSS Ethernet (wired, 3MCB001ACC)
da cb
e f
a
LMC unit
b
RS485 cable
c
Access point (external router)
d
Devices
e
Gateway µBOSS
f
LAN cable
