D-EIMHP01812-24_00EN 10/47
3 STORAGE
If it is necessary to store the unit before installation, it is necessary to observe some precautions:
• do not remove the protective plastic;
• protect the unit from dust, bad weather and any rodents;
• do not expose the unit to direct sunlight;
• do not use heat sources and / or open flames near the machine.
Although the unit is covered with a heatshrink plastic sheet, it is not intended for longterm storage and must be removed
and replaced by tarpaulins or the like, more suitable for a longer period.
Environmental conditions must be within the following limits:
• Minimum ambient temperature: -25 °C
• Maximum ambient temperature +48 °C
• Maximum R.H.: 95% not condensing
Storage at a temperature below the minimum or over the maximum values can cause damage to the components. Storage
in a humid atmosphere may damage electrical components.
3.1 Operation limits
Operation out of the mentioned limits may damage the unit. In case of any doubt contact the manufacturer
representative. In the following figure are illustrated the operation ranges both in cooling and heating mode, in terms of
Leaving water temperature (LWT) and Ambient temperature (OAT).
OPERATION RANGE COOLING – EWYE-CZ
Figure 1 - Operating limits on EWYE-CZ in cooling mode
-30
-20
-10
0
10
20
30
40
50
60
-20 -15 -10 -5 0 5 10 15 20 25
OAT [
°C]
ELWT [°C]
Ref. 1
Ref. 2
